MACHINE
SPECIFICATIONS
Motor
Type ..........................................................................................TEFC Capacitor Start Induction
Class .....................................................................................................................Class "F"
Horsepower ................................................................................................................. 3 HP
Voltage ...................................................................................................................... 220V
Phase ....................................................................................................................... Single
Amps .......................................................................................................................... 22A
Speed .................................................................................................................. 3450 RPM
Cycle ........................................................................................................................ 60 Hz
Number Of Speeds ............................................................................................................. 1
Power Transfer .................................................................................................... Direct Drive
Bearings ............................................................................................... Sealed and Lubricated
Main Specifications
Operation
Maximum Air Flow ............................................................................................. 1489 CFM
Maximum Static Pressure (Inches of Water) .................................................................... 10.2
Intake Hole Size ........................................................................................................ 8"
Collection Drum Capacity ................................................................................... 55 Gallons
Canister Filter Capacity ............................................................................... 0.2–2.0 Microns
Lower Bag
Number ................................................................................................................... 2
Capacity ................................................................................................ 4.3 cu. ft. each
Diameter x Length ....................................................................................... 20"D x 23
5
⁄
8
"L
Canister Filter
Number ................................................................................................................... 2
Filter Surface Area ..................................................................................90.42 sq. ft. each
Diameter x Length ....................................................................................19
3
⁄
4
"D x 15
3
⁄
4
"L
Impeller Information
Type .............................................................................................................Radial Fin
Diameter .............................................................................................................14
1
⁄
2
"
Blade Thickness ........................................................................................................
1
⁄
8
"
Overall Dimensions
Weight .................................................................................................................. 375 lbs.
Length x Width x Height .................................................................................67"L x 44"W x 80"H
Foot Print (Length x Width) ..................................................................................... 67"L x 44"W
Construction Materials
Lower Bag ......................................................................................................... Clear Plastic
Canister Filter ........................................................................................... Spun Bond Polyester
Frame ........................................................................................................................Steel
Impeller .......................................................................................................... Riveted Steel
Impeller Housing ...........................................................................................................Steel
Cyclone ......................................................................................................................Steel
Collection Drum ............................................................................................................Steel
MOdEl W1816
3HP lOW-PROFIlE CYClONE dUST COllECTOR
Model W1816 Machine Specifications, Page 1 of 2
