Star Trac E-TRi - Manual (Page 20)

S
TEP
8
Now that the PVS is mounted to the Treadmill, you
need to route the wires to their proper places.
Take the coax cable and feed it all the way
down the treadmill neck.
Feed the DC power cable from the treadmill
neck through the center console hole.
Next take the Head Phone Jack cable from the
PVS neck and connect it to the Head Phone Jack.
Now feed the other (3) cables through the dis-
play and out the center console hole.
S TEP 9
Take the Entertainment Center Console from the
PVS Kit.
1
3
2
4
20 STAR TRAC P
ERSONAL
V
IEWING
S
CREEN
O
WNER
’
S
G
UIDE
Center
Console
Ground
Keypad Tail
Cable
Window
2
7
5
6
Bottom View
Center Console
Hole
1
2
4
3
Backside of
Entertainment
Center Console
(2) DC Power
Connectors
RCA
Connectors
PVS Remote
Connector
3
4
