Star Micronics RS232 User Manual

Page 42

Text mode
Original mode

– 38 –

STAR MODE

FUNCTION

Vertical tab

CODE

HEX

REMARKS

Prints the current line and feeds the paper to the next vertical tab
stop and moves the print position to the left margin.
Performs paper feed if no vertical tabs are set or if the current line
is at or below the last vertical tab stop.

FUNCTION

Set line spacing to 4 mm

CODE

“z”

“1”

or “z”

<1>

HEX

REMARKS

Sets the distance the paper advances in subsequent line feeds to
4 mm.

FUNCTION

Set line spacing to 3 mm

CODE

“0”

HEX

REMARKS

Sets the distance the paper advances in subsequent line feeds to
3 mm.

FUNCTION

One time n/4 mm feed

CODE

“J”

HEX

REMARKS

Performs a line feed of n/4mm once only.
The value of n is 1 to 255.
Space setting for lines is not changed.
