Star Micronics RS232 User Manual
Page 31
– 27 –
STAR MODE
CODE 39, NW-7, ITF
CODE 39, NW-7
ITF
1
Narrow : wide
2:6 dots
2:5 dots
2
Narrow : wide
3:9 dots
4:10 dots
3
Narrow : wide
4:12 dots
6:15 dots
4
Narrow : wide
2:5 dots
2:4 dots
5
Narrow : wide
3:8 dots
4:8 dots
6
Narrow : wide
4:10 dots
6:12 dots
7
Narrow : wide
2:4 dots
2:6 dots
8
Narrow : wide
3:6 dots
3:9 dots
9
Narrow : wide
4:8 dots
4:12 dots
When the value of n3 is UPC-E, UPC-A, JAN/EAN-8, JAN/EAN-
13, CODE128 or CODE93, 1(01H) to 3(03H) or “1”(31H) to
“3”(33H) can be set. When the value of n3 is CODE39, NW-7 or
ITF, 1(01H) to 9(09H) or “1”(31H) to “9”(39H) can be set.
n4: Height of bar code
Can be up to 255 dots (31.9mm).
If the bar code height is larger than the line feed amount, the
line feed amount is automatically multiplied by an integer.
di...dk: Bar code data
UPC-E/UPC-A: K = 11 (or 12)
The check digit at the 12th digit is automatically added,
and ignored even if it is specified.
JAN/EAN-8: K = 7 (or 8)
The check digit at the 8th digit is automatically added,
and ignored even if it is specified.
JAN/EAN-13: K = 12 (or 13)
The check digit at the 13th digit is automatically added,
and ignored even if it is specified.
CODE39:
The value of k is optional, and the maximum
value also differs according to the modes (21
digits maximum in mode 7).
The start/stop code (“
*
”) is automatically added.
