C-1

A

PPENDIX

C

S

PECIFICATIONS

Physical Characteristics

Base Unit

Ports
16 10BASE-T/100BASE-TX, with auto-negotiation
One RS232 serial console port fitted using an RJ-45 connector

Media Slots
2 slots for optional 100BASE-FX, 1000BASE-T, or 1000BASE-X (GBIC)
modules

Network Interface
Ports 1-16: RJ-45 connectors, auto MDI/MDI-X

10BASE-T: RJ-45 (100-ohm, UTP cable; Categories 3 or better)
100BASE-TX: RJ-45 (100-ohm, UTP cable; Category 5 or better)

Communication Speed
10 and 100 Mbps

Communication Mode
Full and half duplex

Buffer Architecture
4 Mbytes

Aggregate Bandwidth
8.8 Gbps

Switching Database
8K MAC address entries
