No.51666
DLA-M4000LU DLA-M4000LE
42
Operating the Main Menu (Cont.)
Setting and Adjusting Other Functions (OPTIONS) (Cont.)
Notes
• The selected item is shown in magenta color. Items shown
in gray color cannot be operated or set in the current mode.
• Items to be set (adjusted) are different when AV signals are
input and when computer-system signals are input.
• When you turn the RESIZE function ON, allowing the screen
to be enlarged virtually to its full size for projection (resizing
display), the video image (resolution) becomes coarse.
5 Press MENU/ENTER toward the 2 or 3
mark to select an item to set (adjust).
• To adjust multiple items, repeat steps 4 and 5.
Sets whether to clear the menu display
automatically a fixed time later or not.
(Factory setting : NO)
YES: Clears the display automatically in
about 25 seconds.
NO : Does not clear the display
automatically.
NO YES
Sets whether to show the line display (Y/C,
VIDEO, etc.) at the top of the projected
screen or not. (Factory setting : ON)
OFF: Does not show the line display.
ON : Shows the line display.
(The line display disappears about 5
seconds after it is shown.)
OFF ON
Reverses video image right-to-left.
(Factory setting : OFF)
OFF: For the front method
ON : For upside hanging from the ceiling
OFF
ON
Inversus video image upside-down.
(Factory setting : OFF)
OFF: For normal set-up
ON : For upside hanging from the ceiling
OFF
ON
Sets the clamp pulse’s position at the back
porch (BP) or on the sink tip (ST).
Normally, the clamp is used at BP. If, with
some PCs or workstations, the screen
becomes unstable such as being too dark
or too bright, try to switch to ST.
(factory setting: BP)
BP : The clamp pulse is positioned at the
back porch.
ST : The clamp pulse is positioned on the
sink tip.
BP ST
When the number of pixels (resolution)
sought by the input video is smaller than
that (resolution) of D-ILA device, the video
image is then enlarged to virtually full
screen size of D-ILA device and projected
(resizing display). (Factory setting : ON)
Does not work (cannot be set) for video
system input.
OFF : Does not enlarge the video image for
projection. When the number of
pixels sought by video image is
smaller than that of D-ILA device,
projection takes place on a small
screen size with a black area around
the screen.
ON : Enlarges virtually to the full screen
size of D-ILA device for projection
(resizing display).
OFF ON
Adjustment item Button Adjustment content
MENU AUTO
OFF
LINE DISPLAY
RIGHT LEFT
REV.
TOP BOTTOM
INV.
CLAMP
RESIZE
2 / 3
2 / 3
2 / 3
2 / 3
2 / 3
2 / 3
■ Remote control unit
■ Submenu items
[OPTIONS menu]
(To be continued on the next page)
MEN U/E N T E R
QUICK ALIGN. AV HIDE OPERATE
PRESET
AV
SHIFT ZOOM FOCUS
LENS
U T +
D W –
RGB/COMPUTER
LENS
LOCK
UNLOCK
PAGE BACK PAGE BACK button
MENU/ENTER button
O P T I O N S
M E N U A U T O O F F
L I N E D I S P L A Y
R I G H T L E F T R E V .
T O P B O T T O M I N V .
C L A M P
R E S I Z E
B A C K C O L O R
C O L O R T E M P .
A S P E C T C H A N G E
S L E E P T I M E
L A M P T I M E
N O
O N
O F F
O F F
B P
O N
B L U E
M I D D L E
4 : 3
0 M i n .
1 0 H .
43
Operating the Main Menu (Cont.)
Notes
• The selected item is shown in magenta color. Items shown
in gray color cannot be operated or set in the current mode.
• Items to be set (adjusted) are different when AV signals are
input and when computer-system signals are input.
Setting and Adjusting Other Functions (OPTIONS) (Cont.)
Sets background color when there is no input
signal. (Factory setting : BLUE)
BLUE CYAN BLACK GREEN
YELLOW RED MAGENTA
Sets the color temperature of the video image
being projected. Make adjustment when the
image becomes reddish or bluish. (Factory
setting : MIDDLE)
LOW : Color temperature decreases
(video image becoming reddish).
MIDDLE : Results in middle color
temperature.
HIGH : Color temperature increases
(video image becoming bluish).
LOW MIDDLE HIGH
Sets the vertical-to-horizontal ratio (4 : 3 or 16
: 9) of the video image projected. (Factory
setting : 4 : 3)
4 : 3 : The aspect ratio of the screen
becomes 4 : 3. Set it to 4 : 3 for video
of NTSC, NTSC4.43, PAL, SECAM.
16 : 9: The aspect ratio of the screen
becomes 16 : 9. Set it to 16 : 9 for Hi-
Vision devices (W-VHS VCR, etc.)
4 : 3 16 : 9
Sets the length of sleep time which
automatically brings the projector into stand-
by state. You can select one of the following
sleep times : 10 minutes, 20 minute, 30
minutes, 60 minutes and 0. (Factory setting :
0 minutes)
10
20 30 60 0
If set to “0” minutes, this function does not work.
Adjustment item Button Adjustment content
BACK COLOR
COLOR
TEMP.
ASPECT
CHANGE
SLEEP TIME
2 / 3
2 / 3
2 / 3
2 / 3
¶ To return to the main menu, press the PAGE
BACK button. To finish the main menu, press
PAGE BACK again.
• To finish the menu display from the submenu display (OPTIONS
menu), press PAGE BACK twice.
Note
• When you view a conventional (normal) 4 : 3 video picture, which is not
wide video picture, on the projector’s screen the aspect change function,
the upper and lower parts of the video picture become partially invisible.
View such an original video picture in 4 : 3 mode, respecting the producer’s
intention.
■ Remote control unit
■ Submenu items
O P T I O N S
M E N U A U T O O F F
L I N E D I S P L A Y
R I G H T L E F T R E V .
T O P B O T T O M I N V .
C L A M P
R E S I Z E
B A C K C O L O R
C O L O R T E M P .
A S P E C T C H A N G E
S L E E P T I M E
L A M P T I M E
N O
O N
O F F
O F F
B P
O N
B L U E
M I D D L E
4 : 3
0 M i n .
1 0 H .
[OPTIONS menu]
MEN U/E N T E R
QUICK ALIGN. AV HIDE OPERATE
PRESET
AV
SHIFT ZOOM FOCUS
LENS
U T +
D W –
RGB/COMPUTER
LENS
LOCK
UNLOCK
PAGE BACK PAGE BACK button
MENU/ENTER button
