40
Operating the Main Menu (Cont.)
Adjusting Picture Quality (Cont.)
Gets darker.
(–30
← 0 ← +30)
Gets brighter.
(–30
→ 0 → +30)
Gets lower.
(–30
← 0 ← +30)
Gets higher.
(–30
→ 0 → +30)
Gets less reddish.
(–30
← 0 ← +30)
Gets more reddish.
(–30
→ 0 → +30)
Gets less greenish.
(–30
← 0 ← +30)
Gets more greenish.
(–30
→ 0 → +30)
Gets less bluish.
(–30
← 0 ← +30)
Gets more bluish.
(–30
→ 0 → +30)
Sets a mode which allows easy
text reading.
Resets all adjustment values of
items on the PICTURE quality
menu to the factory-set status
(adjustment values: 0, text
mode: NORMAL).
Adjustment item Button Adjustment content
BRIGHTNESS
CONTRAST
R-GAIN
G-GAIN
B-GAIN
TEXT MODE
ALL RESET
2
3
2
3
2
3
2
3
2
3
2
3
MENU/
ENTER
Note
• There is a relationship between the adjustment of items R-GAIN, G-GAIN,
and B-GAIN and that of item CONTRAST. For example, when adjustment
values are : R-GAIN: 0, G-GAIN: 5, B-GAIN: 0, and CONTRAST: 0, changing
CONTRAST to 1 changes the adjustment values as follows: R-GAIN: 1, G-
GAIN: 6, and B-GAIN: 1.
Also, when the adjustment value of any of R-GAIN, G-GAIN, and B-GAIN
has reached -30 (minimum) or +30 (maximum), CONTRAST cannot be
adjusted to any higher value. For example, when R-GAIN is 0, G-GAIN is 5,
B-GAIN is 0, and CONTRAST is 0, increasing CONTRAST allows the other
adjustment values to increase until R-GAIN: 25, G-GAIN: 30, and B-GAIN:
25, then CONTRAST becomes 25 and cannot be adjusted to any higher
value.
¶ To return to the main menu, press the PAGE
BACK button. To finish the main menu, press
PAGE BACK again.
• To finish the menu display from the submenu display (PICTURE
menu), press PAGE BACK twice.
NORMAL TEXTE1
TEXTE2
NORMAL TEXTE1
TEXTE2
■ Remote control unit
■ Submenu items
Notes
• The selected item is shown in magenta color. Items shown
in gray color cannot be operated or set in the current mode.
• Adjustment items (on the PICTURE menu) are different when
AV signals are input and when computer-related signals are
input.
[PICTURE menu]
MEN U/E N T E R
QUICK ALIGN. AV HIDE OPERATE
PRESET
AV
SHIFT ZOOM FOCUS
LENS
U T +
D W –
RGB/COMPUTER
LENS
LOCK
UNLOCK
PAGE BACK PAGE BACK button
MENU/ENTER button
P I C T U R E
( S X G A 2 )
B R I G H T N E S S
C O N T R A S T
R - G A I N
G - G A I N
B - G A I N
T E X T M O D E N O R M A L
A L L R E S E T 0
0
0
0
0
41
Operating the Main Menu (Cont.)
Submenu item (OPTIONS)
Setting and Adjusting Other Functions (OPTIONS)
The following optional functions can be set (adjusted).
• MENU AUTO OFF • LINE DISPLAY • RIGHT LEFT REV.
• TOP BOTTOM INV. • CLAMP • RESIZE
• BACK COLOR • COLOR TEMPERATURE
• ASPECT CHANGE • SLEEP TIME • LAMP TIME
Memo
About the lamp use time
The lamp use time indicates the accumulated used hours of the light-source
lamp and cannot be set or adjusted. When you have replaced with a new
light-source lamp, reset the lamp use time.
Note
• The RESIZE function works for only computer system input. It does not work
for video system input.
1 Press the MENU/ENTER button.
• The main menu appears on the screen.
2 Press MENU/ENTER toward the 5 or ∞
mark to select a submenu item,
“OPTION”.
• The selected item (displayed in text) is shown in magenta color
on the screen.
3 Press the MENU/ENTER button.
• The submenu items of the OPTIONS menu are displayed.
(OPTIONS menu)
■ Remote control unit
■ Main menu
Note
• The selected item is shown in magenta color. Items shown
in gray color cannot be operated or set in the current mode.
• Items to be set (adjusted) are different when AV signals are
input and when computer system signals are input.
4 Press MENU/ENTER toward the 5 or ∞
mark to select an item to set (adjust).
• The selected item (displayed in text) is shown in magenta color.
(To be continued on the next page)
N T S C ( 4 8 0 i )
E N G L I S H
P I X E L C L O C K
P O S I T I O N
P I C T U R E
O P T I O N S
S O U R C E
C H A N N E L
U S E R S O U R C E S E T U P
D I S P L A Y S I Z E
D E C O D E R
L A N G U A G E
Y P B P R
C H : 1
H D T V ( 1 0 8 0 i )
MEN U/E N T E R
QUICK ALIGN. AV HIDE OPERATE
PRESET
AV
SHIFT ZOOM FOCUS
LENS
U T +
D W –
RGB/COMPUTER
LENS
LOCK
UNLOCK
PAGE BACK PAGE BACK button
MENU/ENTER button
O P T I O N S
M E N U A U T O O F F
L I N E D I S P L A Y
R I G H T L E F T R E V .
T O P B O T T O M I N V .
C L A M P
R E S I Z E
B A C K C O L O R
C O L O R T E M P .
A S P E C T C H A N G E
S L E E P T I M E
L A M P T I M E
N O
O N
O F F
O F F
B P
O N
B L U E
M I D D L E
4 : 3
0 M i n .
1 0 H .
