JVC YU30052-513-2 - Manual (Page 38)

38
USER MAINTENANCE
After Use
1 Set the power switch to POWER OFF to turn off the
camcorder.
2 Slide EJECT to open the cassette holder, then remove
the cassette.
3 Close and lock the cassette holder by pressing
PUSH.
4 Press BATT. RELEASE to remove the battery pack.
5 Slide the LENS COVER open/close switch to close
the lens cover.
Cleaning The Camcorder
CLEAN EXTERIOR
1 Wipe gently with a soft cloth.
CLEAN LENS
2 Blow it with a blower brush, then wipe gently with
lens cleaning paper.
REMOVE EYEPIECE
3 Turn the eyepiece counterclockwise and pull it out.
CLEAN VIEWFINDER
4 Remove dust using a blower brush.
RE-ATTACH EYEPIECE
5 Align the marks, re-attach the eyepiece and turn it
clockwise.
NOTES:
● Avoid using strong cleaning agents such as benzine or
alcohol.
● Cleaning should be done only after the battery pack
has been removed or other power units have been
disconnected.
● Mold may form if the lens is left dirty.
LENS COVER
open/close switch
EJECT
PUSH
Marks
BATT. RELESE Set to “POWER OFF”.
Remove.
