21
SEL
F1
F2
FOCUS EXP. F1 F2
F 1 + F 1 +
Manual Focus
NOTE:
You should already have made the necessary viewfinder
adjustments (
੬
pg. 9). If you haven’t, do so before
continuing.
SELECT MODE
1 Press Function SEL. until “FOCUS” appears to the
right of F1.
ADJUST FOCUS
2
A TO FARTHER SUBJECT
2 While holding down F1, slide the power zoom
switch to T. The Manual Focus indications “ ”
appear and “ ” blinks.
Go to step 3.
B TO NEARER SUBJECT
While holding down F1, slide the power zoom
switch to W. The Manual Focus indications
“
” appear and “ ” blinks.
Go to step 3.
LOCK FOCUS
3 Release the power zoom switch. The focus
indication is replaced by the focus lock indication
“
” and the adjusted focus is locked in.
RELEASE MANUAL FOCUS MODE
4 Press F1. The Manual Focus mode is immediately
released and the focus lock indication disappears.
NOTES:
● Be sure to focus the lens in the maximum telephoto
position when you use the Manual Focus mode. If you
focus in on a certain subject in the wide-angle position,
sharply focused images cannot be obtained when
zoomed up because the depth-of-field is reduced at
longer focal lengths.
● Two manual focusing speeds are available. For
slow-speed, push the switch slightly and hold that
position. For fast-speed, push the switch fully.
● When the focus level cannot be adjusted any farther or
closer, “ ” or “
” will blink.
F1 button F2 button
Function SEL.
button
Power zoom switch
Viewfinder
