Table 21: N+N Power Supply Requirements for EX8208 Switch
Configurations Using 2000 W AC Power Supplies (Junos OS Release 10.2
or Later Only)
Power Supplies
Needed for N+N Power Supplies
Needed (N)
Input Voltage
Switch
Configuration
2 1 High-voltage line
(200–240 VAC) Base
2 1 Low-voltage line
(100–120 VAC)
6 3 High-voltage line
(200–240 VAC) Fully loaded with
8-port SFP+ line
cards
Not Supported 4 Low-voltage line
(100–120 VAC)
Table 22: N+N Power Supply Requirements for EX8208 Switch
Configurations Using 3000 W AC Power Supplies (Junos OS Release 10.2
or Later Only)
Power Supplies
Needed for N+N Power Supplies
Needed (N)
Input Voltage
Switch
Configuration
2 1 High-voltage line
(200–240 VAC) Base
4 2 High-voltage line
(200–240 VAC) Fully loaded with
8-port SFP+ line
cards
Table 23: N+N Power Supply Requirements for EX8216 Switch
Configurations Using 2000 W AC Power Supplies (Junos OS Release 10.2
or Later Only)
Power Supplies
Needed for N+N Power Supplies
Needed (N)
Input Voltage
Switch
Configuration
2 1 High-voltage line
(200–240 VAC) Base
4 2 Low-voltage line
(100–120 VAC)
Not supported 5 High-voltage line
(200–240 VAC) Fully loaded with
8-port SFP+ line
cards
Not supported Not supported Low-voltage line
(100–120 VAC)
45 Copyright © 2010, Juniper Networks, Inc.
Chapter 2: Component Descriptions
