Table 7: LCD Panel Menu Options for the EX8200 Switch (continued)
Description Menu
The Status menu has the following options:
• Switch fabric status—Choose one of the following:
• Press Enter to display the status of the switch fabric in the SRE modules (SRE0 and SRE1) in EX8208
switches and the SF modules (SF) in EX8216 switches: OK, Fld (failed), ABS (absent)
• Press Menu to go to the next option in the Status menu.
• Power supply status (1)—Choose one of the following:
• Press Enter to display the status of power supplies 0 and 1: OK, Fld, ABS.
• Press Menu to go to the next option in the Status menu.
• Power supply status (2)—Choose one of the following:
• Press Enter to display the status of power supplies 2, 3, 4, and 5: OK, Fld, ABS.
• Press Menu to go to the next option in the Status menu.
• Environment status—Choose one of the following:
• Press Enter to display the status of the fan tray(s) and the chassis temperature:
• Fan tray(s) status: OK, Fld, ABS
• Chassis temperature status: OK, High, Shutdown
• Press Menu to go to the next option in the Status menu.
• Junos version status—Choose one of the following:
• Press Enter to display the version of Junos OS for EX Series switches loaded on the switch.
• Press Menu to go to the next option in the Status menu.
• EXIT STAT MENU?—Choose one of the following:
• Press Enter to exit the Status menu.
• Press Menu to return to the Switch fabric status option.
If you do not want users to use Status menu options, disable the entire menu or individual menu options. See
Configuring the LCD Panel on EX Series Switches (CLI Procedure).
Status
Copyright © 2010, Juniper Networks, Inc. 20
Complete Hardware Guide for EX8208 Ethernet Switches
