Ad-081ge – JAI AD-081GE User Manual
Page 75
AD-081GE
74
Support DHCP
GevSupportedConfigurati
onDHCP
Bit 29: LLA
0. DHCP and LLA bits must
be on.
Support Persistent IP
GevSupportedConfigurati
onPersistentIP
0x0014
Current IP configuration
LLA
GevCurrentIPConfiguratio
nLLA
RW
4
Bit 31: persistent
Bit 30: DHCP
Bit 29: LLA
Bits can be OR-ed. LLA is
always activated and is read
only.
LLA is
always
true
Current IP configuration
DHCP
GevCurrentIPConfiguratio
nDHCP
Current IP configuration
Persistent IP
GevCurrentIPConfiguratio
nPersistentIP
0x0024
Current IP address
GevCurrentIPAddress
R
4
0x0034
Current Subnet Mask
GevCurrentSubnetAddress R
4
0x0044
Current Default Gteway
GevCurrentDefaultGatew
ay
R
4
0x0200
First URL
GevFirstURL
R
512
File extension .XML
indicates uncompressed
text file. File extension .ZIP
indicates compressed using
ZIP.
0x0400
Second URL
GevSecondURL
R
512
0x0600
Number Of Interfaces
GevNumberOfInterfaces
R
4
Indicates the number of
physical network interfaces
on
this device.
0x064C
Persistent IP Address
GevPersistentIPAddress
RW
4
Valid if Persistent IP is
enabled
0x065C
Persistent Subnet Mask
GevPersistentSubnetMask
RW
4
Valid if Persistent IP is
enabled
0x066C
Persistent Default
Gateway
GevPersistentDefaultGate
way
RW
4
Valid if Persistent IP is
enabled
0x0900
Message Channel Count
GevMessageChannelCount R
4
number of available
message channel
0x0904
Stream Channel Count
GevStreamChannelCount
R
4
number of available stream
channel
0x0934
Supported Optional
Commands User-defined
Name
GevSupportedOptionalCo
mmandsUser-definedNam
e
R
4
Bit 31:multiple read
Bit 30:WRITEMEM
Bit29:
PACKETRESEND
Bit 28:EVENT
Bit 27:EVENTDATA
Bit 1:Serial No.
Bit 0:User defined name
0=false
1=True
This is a capability register
indicating which one of the
non-mandatory GVCP
commands are supported by
this
device.
Supported Optional
Commands Serial number
GevSupportedOptionalCo
mmandsSerialnumber
Supported Optional
Commands EVENTDATA
GevSupportedOptionalCo
mmandsEVENTDATA
Supported Optional
Commands EVENT
GevSupportedOptionalCo
mmandsEVENT
Supported Optional
Commands PACKET
RESEND
GevSupportedOptionalCo
mmandsPACKETRESEND
Supported Optional
Commands WRITEMEM
GevSupportedOptionalCo
mmandsWRITEMEM
Supported Optional
Commands Concatenation
GevSupportedOptionalCo
mmandsConcatenation
0x0938
Heartbeat Timeout
GevHeartbeatTimeout
RW
4
0 ～4294967295
0
0x093C
Timestamp Tick
Frequency
GevTimestampTickFreque
ncy
R
4
Timestamp tick
frequency is 0 if
timestamp is not
supported.
In milliseconds.
Internally, the heartbeat is
rounded according to the
clock used for heartbeat.
0x0940
GevTimestampTickFreque
ncy
R
4
64-bit value indicating the
number of timestamp clock
ticks in 1 second. This
register holds the most
significant
bytes.
