AD-081GE
71
0xB07C
Line Selector
Line3-Optical Out 2
Line3
RW
4
Bit24:Line Inverter
0=False (Active High)
1=True(Active Low)
2:LVAL2
3:DVAL1
4:DVAL2
5:FVAL1
6:FVAL2
7:EEN1
8:EEN2
9:Line4-Ooptical In 1
10:Line5-Optical In 2
11:Line8-LVDS IN
12:Line6-TTL In 1
13:Line7-TTL In 2
16:Pulse Generator 0
17:Pulse Generator 1
18:Pulse Generator 2
19:Pulse Generator 3
20:User Output 0
21:User Output 1
22:User Output 2
23:User Output 3
0xB080
Line Selector
Line4-Optical In 1
Line4
RW
4
0xB084
Line Selector
Line5-Optical In2
Line5
RW
4
0xB088
Line Selector
Line6-TTL In 1
Line6
RW
4
0xB08C
Line Selector
Line7-TTL In 2
Line7
RW
4
0xB090
Line Selector
Line8-LVDS In
Line8
RW
4
Line Mode
LineMode
0=Input 1=Output
Line Format
LineFormat
0=Internal Logic Signal
1=TTL
2=LVDS
3=Opto-coupled
0xB0B0
Line status
R
4
See the current input and
output line
Pulse Generator
Address Display Name
(JAI Control Tool)
GenICam name
Read /
Write
Size Value / Range of value
Description
Default
value
0xB004
Clock Pre-scaler
ClockPreScaler
RW
4
0x000
0x001
0x002
|
0xFFF
Bypass
Divide by 2
Divide by 3
|
Divide by 4096
0
0xB008
Pulse Generator Length 0
PulseGeneratorLength0
RW
4
1～1048575
Defines the length of the
counter 0
1
0xB00C
Pulse Generator Start
Point 0
PulseGeneratorStartPoint
0
RW
4
0～1048574
Defines the starting point of
the counter 0
0
0xB010
Pulse Generator Repeat
Count 0
PulseGeneratorRepeatCo
unt0
RW
4
0 - 255
Defines the repeat count of
the counter 0
0
0xB014
Pulse Generator End Point
0
PulseGeneratorEndPoint0
RW
4
1～1048575
Defines the end point of the
counter 0
1
0xB018
Clear Mode for the Pulse
Generator 0
PulseGeneratorClear0
RW
4
0 :Free Run
1:High Level
2: Low Level
4: Rising Edge
8: Falling Edge
0
0xB01C
Pulse Generator Length 1
PulseGeneratorLength1
RW
4
1～1048575
Defines the length of the
counter 1
1
0xB020
Pulse Generator Start
Point 1
PulseGeneratorStartPoint
1
RW
4
0～1048574
Defines the starting point of
the counter 1
0
0xB024
Pulse Generator Repeat
Count 1
PulseGeneratorRepeatCo
unt1
RW
4
0 - 255
Defines the repeat count of
the counter 1
0
0xB028
Pulse Generator End Point
1
PulseGeneratorEndPoint1
RW
4
1～1048575
Defines the end point of the
counter 1
1
