AD-081GE
65
12.2. Specifications Table
Specifications
AD-081GE
Scanning system
Progressive scan
Frame Rate Full scan
30.0 frames / sec. Progressive (768 lines/frame)
Pixel clock
33.75MHz
Line frequency
23.768 KHz (1420 pixel clocks / line)
Image sensor
1/3 inch Monochrome IR IT CCD
Sensing area
4.76 (H) x 3.57 (V) mm
Cell size
4.65 (H) x 4.65 (V) µm
Active pixels
1024(H) x 768 (V)
Pixels in Video output Full
Variable Partial
Vertical binning
1024 (h) x 768 (v) 30.0 fps. H = 23.768 kHz
Scan height 1 to 760 lines,
Start line 8 to 768
1024(h) x 384(v), 49.30 fps (max.) H=19.62 KHz
Sensitivity on sensor
0.34 lux (Max. Gain, Shutter OFF, 50% Video Level)
S/N ( dB)
More than 54 dB (0dB)
Iris video output, Analogue
0.7 V p-p (without Sync)
Digital Video Output
Via RJ-45 x 2 (GigE1 and GigE2)
Mono8, Mono10, Mono10_Packed, Mono12_Packed, Mono12
Input signals
(TTL/75Ω) x2, LVDS x 1 HIROSE 6-pin
OPT x2 HIROSE 12-pin
Output signals
TTL x 1 Hirose 6-pin
OPT x 2 Hirose 12-pin
Gain
Manual Gain: -3dB to +21dB (o.35dB step)
AGC: -3dB to +21dB
Knee compensation
Knee point and knee slope
LUT/Gamma
1.0/0.6/0.45/LUT
Shading compensation
ON/OFF
Synchronization
Int. X-tal
GPIO Module
Input /Output switch
Clock Generator(one)
Pulse generator (Four)
Configurable 21-in / 14-out switch
12 bit counter based on pixel clock
20-bit counter programmable for length, stat point, stop point , repeat
Hardware Trigger mode
Edge Pre-select, Pulse width control, RCT, PIV, Frame delay, Sequence
OB area transfer mode
ON / OFF
Event message
Exposure start, Exposure end, Trigger IN, Video start, Video end
Electronic Shutter
Programmable Exposure
Exposure Time Abs
GPIO plus Pulse width
Auto shutter
20 µs to 792L(33.3ms) in 1L step
µsec – user definable. Same range as PE
Max. 2 sec (fine setting with GPIO and pulse width control)
1/30 to 1/10000 sec
Accumulation
LVAL synchronous or LVAL asynchronous automatic selection
Interface
Gigabit Ethernet (IEEE802.3, ATA GigE Vision Standard) 2 lines
Functions controlled via GigE
Vision Interface
Shutter, Gain, Black Level, Trigger mode, Readout mode,
GPIO setup, ROI (GenICam mandatory functions )
GigE Vision Streaming Control
Packet size, Delayed (Frame) readout, inter-packet delay
Jumbo frame can be set at max. 16K (16020), Default packet size is 1476 Byte.
Indicators on rear panel
Power, Hardware trigger, GigE Link, GigE activity
Lens Mount
C-Mount (Rear protrusion less than 4mm). Designed For 3CCD camera
Flange back
17.526mm Tolerance 0 to – 0.05mm
Operating temperature
-5
C to +45
C
Operating humidity
20 to 80% (non-condensing)
