AD-081GE
73
Sequence Acquisition Mode
Address
Display Name
(JAI Control Tool)
GenICam name
Read /
Write
Size Value / Range of value
Description
Default
value
Sequence Selector
SequenceSelector
Sequence Selector
Value
0=Sequence 1
1=Sequence 2
2=Sequence 3
3=Sequence 4
4=Sequence 5
5=Sequence 6
7=Sequence 8
8=Sequence 9
9=Sequence 10
Sequence Selector value is
the INDEX for each
sequence。
0xC000
Sequence Exposure Time
Raw
SequenceExposureTimeRa
w
RW
4
0 - 792
Shutter value Base Address
INDEX=0 to 9
(Base Address + Index *4)
792
0xC078
Sequence Master Gain
Raw
SequenceMasterGain
RW
4
-89 to 593
Gain value Base Address
INDEX=0 to 9
(Base Address + Index *4)
0
0xC0FC
Sequence ROI Size X
SequenceROISizeX
RW
4
8 - 1024
ROI width value Base
Address
INDEX=0 to 9
(Base Address + Index *4)
Width
max
0xC124
Sequence ROI Size Y
SequenceROISizeY
RW
4
8 - 768
ROI Height value Base
Address
INDEX=0 to 9
(Base Address + Index *4)
Height
Max
0xC14C
Sequence ROI Offset X
SequenceROIOffsetX
RW
4
0 - 1016
ROI H Offset value Base
Address
INDEX=0 to 9
(Base Address + Index *4)
0
0xC174
Sequence ROI Offset Y
SequenceROIOffsetY
RW
4
0 - 760
ROI V Offset value Base
Address
INDEX=0 to 9
(Base Address + Index *4)
0
0xC19C
Repeat Count in Each Step
SequenceRepeatCountInE
achStep
RW
4
1 to 255
Sequence repeat count
value Base Address
INDEX=0 to 9
(Base Address + Index *4)
0
0xC0F0
Reset Sequence Settings
SequenceResetCommand
RW
4
1 only
Sequence3 reset
1
0xC0F4
Sequence Repetition
Count
SequenceRepetitions
RW
4
0 to 255
Sequence repeat count
0
0xC0F8
Last Sequence
SequenceEndingPosition
RW
4
1 to 10
Last sequence number
setting
1
GigE Transport Layer
Address
Display Name
(JAI Control Tool)
GenICam name
Read /
Write
Size Value / Range of value
Description
Default
value
0xA418
Payload size
PayloadSize
R
4
Return image size of 1
frame
0x0000
GigE Major Version
GevVersionMajor
R
4
Version of the GigE
Standard to which the
device is
compliant.
0001
GigE Minor Version
GevVersionMinor
0000
0x0004
Is Big Endian
GevDeviceModeIsBigEndia
n
R
4
0:Littel-endian
1:Big-endian
0:Little endian 1:Big endian
1:UTF-8
1
Character set
GevDeviceModeCharacter
Set
0:Unknown ,1:UTF-8
1
0x0008
MAC address
GevMacAddress
R
4
Upper 4 bytes of the MAC
address
0x000c
MAC address
GevMacAddress
R
4
Lower 4 bytes of the MAC
address
0x0010
Support LLA
GevSupportedIPConfigura
tionLLA
R
4
Bit 31: persistent
Bit 30: DHCP
Bits can be OR-ed. All other
bits are reserved and set to
All True
