Ad-081ge, Fig.44 edge pre-select lval synchronous details – JAI AD-081GE User Manual
Page 52

AD-081GE
51
Expos ur e Del ay
(Exposure)
DATA out
Data out Del ay
1 to 2L
13 to 14L
Ext.Tri g
FVAL
EEN
LVAL
Exposure Pri od
1L = 1420cl ock (42.07us)
14. 2us
Fig.42 Edge Pre-select LVAL asynchronous details
Fig.43 Edge Pre-select LVAL synchronous
Exposure Del ay
1. 5L
Dat a out Del ay
(Exposure)
DATA out
t1+1L( Max)
13. 5L
Ext.Tri g
FVAL
EEN
LVAL
Exposure Pri od
1L = 1420Cl ock (42.07us)
When the LVAL Sync Accum. : t1=0.5 to 1.5L
When the LVAL Async Accum.: t1=0.5L
Fig.44 Edge Pre-select LVAL synchronous details
