AD-081GE
61
10.6.2 Readout mode (0xA098) 1:ASYNC
Sensor
BW-1
BW-2
Auto Iris
output
(note2)
Trigger Input
Trigger 1 : Valid
Trigger 2 : Valid
ID
Value
Mode
Shutter
Fast
dump
ON
Smear
less
Shutter
Fast
dump
ON
Smear
less
00
Continuous
Yes
Yes
No
Yes
Yes
No
Yes
01
Edge
Pre-select
(EPS)
Yes
Yes
Yes
Yes
Yes
Yes
No
02
Pulse
Width
Control
(PW)
Not
applicable
Yes
Yes
Not
applicable
Yes
Yes
No
04
RCT
Yes
Yes
Automatically
ON
Yes
Yes
Automatically
ON
Yes
32
PIV1
No
No
No
No
No
No
No
64
PIV2
No
No
No
No
No
No
No
128
PIV3
No
No
No
No
No
No
No
09
Sequential
EPS
Yes
Yes
No
Yes
←
(note1)
No
No
17
Delayed
Readout
EPS
Yes
Yes
Yes
Yes
←
←
No
18
Delayed
Readout
PWC
Not
applicable
Yes
Yes
Not
applicable
←
←
No
Note 1: “
←”
means that the setting depends on BW-1.
Note 2: Video signal for auto iris uses the signal from BW-1. It can be changed by register.
