16
EN PLAYBACK (cont.)
PRO HD System
Playback
This PRO HD system can perform playback of the D-VHS
tape recorded by the MPEG2-TS signal.
This VCR can check the tape condition during playback
(and recording), and realizes the best possible pictures.
● Turn on the VCR and the TV, and select the AV mode
on the TV.
● Set the [VCR/TV/CABLE/DBS] selector on the Remote
to [VCR].
Please refer to next page, when you playback the tape
on which the password was set up.
1 Load a D-VHS cassette
Make sure the window side is up, the rear label
side is facing you and the arrow on the front of
the cassette is pointing towards the VCR.
Do not apply too much pressure when inserting.
● The VCR turns on automatically.
● The tape will run for a few seconds while the
VCR searches for the tape number. If the tape
number is found, it will be shown on the TV
screen if “SUPERIMPOSE” is set to “ON”
(
੬ page 39).
● The counter is reset automatically, however, it is
not completely reset to “0:00:00”.
● If the cassette’s record safety tab has been
removed, playback begins automatically.
● The [D-VHS] indicator lights up.
2 Start playback
Press [PLAY ( 3 )].
● Tape speed is automatically detected.
To stop playback
Press [STOP ( 7 )] on the Remote or [STOP/EJECT ( 7/0 )]
on the front panel.
To rewind the tape (when it is not running)
Press [REW ( 1 )].
To fast-forward (when it is not running)
Press [FF ( ¡ )].
To eject the tape
Press [STOP/EJECT ( 7/0 )] on the front panel when the
tape is not running.
● You can also eject the cassette when the VCR is turned
off.
To turn off the VCR
Press [POWER].
IN F-1
+
[POWER]
[STOP/EJECT
( 7/0)]
1 2
[REW ( )]
[FF ( )]
VCR
TV
CABLE
/DBS
[POWER]
[REW( 1)]
2
[FF( ¡)]
[STOP( 7)]
