Network remote control
ENCODE PARAMETERS
Clicking ENCODE PARAMETERS on the left of the Streamcorder screen displays the ENCODE PARAMETERS
screen for performing video/audio compression settings.
Click the OK icon to
confirm setting.
Screen selection
Setting
Select the setting from the
pull-down menu.
Setting range
ⅷindicates default factory setting.
Item
Frame Size
Bit Rate
Frame Rate
Description
Sets the video compression size.
320
× 240: Sets the image size to 320 × 240 pixels.
160
× 120: Sets the image size to 160 × 120 pixels.
* The input image for a 160x120 pixel image is 160x120 pixels. However, they will
be 160x128 pixels when compressed.
Sets the video streaming speed.
Sets the frame rate per second. The maximum tranmitted frames per second varies de-
pending on the FRAME SIZE and BIT RATE settings as shown below:
\ NTSC signal
\ PAL signal
* The frame rates shown in the table are not guaranteed values.
Setting
ⅷ 320 Ч 240
160
Ч 120
56K (bps)
128K (bps)
256K (bps)
ⅷ 384K (bps)
512K (bps)
MAX
ⅷ MID
MIN
FRAME SIZE
BIT RATE
320
Ч 240
160
Ч 120
MAX
MID
MIN
MAX
MID
MIN
512K
15
10
7.5
30
15
10
384K
15
10
7.5
30
15
10
256K
15
7.5
5
30
15
7.5
128K
7.5
5
3
15
10
7.5
56K
3
1
1
10
7.5
5
FRAME SIZE
BIT RATE
320
Ч 240
160
Ч 120
MAX
MID
MIN
MAX
MID
MIN
512K
12.5
5
5
25
12.5
12.5
384K
12.5
5
5
25
12.5
5
256K
12.5
5
5
25
12.5
5
128K
5
5
1
12.5
12.5
5
56K
1
1
1
12.5
5
5
→ OVER
