30
NE T WOR K
OR
T W
E
N
K
A CK
P
O N
C
I G
F
E N CO DE
MPE G R EC
S P I T
L
MOV I E CL I P
MENU R E S E T
PAGE B ACK
S
. .
. .
S E T
E T
P
U
P
U
T
. .
S E
P
U
MA I N
N CE L
C A
C F REC : P
' S E '
T
( WMP u n d r 8 )
e
S H
U
( C F V i e w r )
e
TC 0 0 : 0 0 :
0
0 0 . 0
Set to SPLIT
LCD screen
LAN card display
CH1
NDF
12
H
34
M
34
S
10
F
FREE
CH2
PLAY
SP222
min
01/02/03
01:23:45
INS
AM
OVER
48k
TC
L
dB
0
10
20
30
40
OVER
W
Y/C
VA
SYNC
‰
e
CF
ENCODE SETUP
menu screen
Using LAN card/LAN terminal
Recording to DV tape and Client PC Independently
1.
Insert a LAN card into the Network Pack, or connect a LAN cable into the LAN
terminal.
2.
Turn on the BR-DV6000 power.
Check to see that the LAN card display is showing on the LCD screen. (When
using a LAN card)
3.
Select the input signal using the INPUT SELECT switch.
4.
Press the MENU button to display the TOP MENU screen.
5.
Set the NETWORK PACK CONFIG menu screen.
q Set MPEG REC to “SPLIT”.
w Set the video/audio compress in the ENCODE SETUP menu screen. (
☞ page 8)
e When completed, press the MENU button to return to the normal screen.
6.
When operating Streamproducer or Streamcapture in the Trigger mode and mak-
ing network connection with SA-DV6000, sending of streaming video/audio data
will start from the LAN card or LAN terminal.
When pressing the SET button of BR-DV6000, recording to the disk will start.
● The LAN card display on the LCD screen will be as follows:
e
: Red display during data transmission. (When using a LAN card)
7.
To stop recording to the disk, press the SET button.
8.
Press the SET button on the side to resume recording to the disk.
9.
To end operation, first disconnect the network connection and then turn off the
power.
Lastly, remove the LAN card.
Memo
● Pressing the SET button does not record the image onto the inserted DV cas-
sette tape.
NETWORK PACK CONFIG
menu screen
BR-DV6000
PROFESSIONAL
MENU
RESET
A.DUB
EJECT
COUNTER
AUDIO
INPUT
SELECT
MONITOR OUTPUT
REMOTE
LOCAL
CTL
L
MIX
R
CH-1/2
MIX
CH-3/4
DV
LINE
Y/C
(CPN)
TC
UB
REW
STOP
FF
REC
OPERATE
PLAY
PAUSE
DISP
SET
SEARCH+
BLANK
CUE UP
HOLD
PHONES
REC LEVEL
CH-1/3
CH-2/4
MIC
SEARCH–
Mini
INPUT SELECT switch
MENU button
SET button
Displayed only when setting
MPEG REC to SPLIT.
