20
LAN connections
Wired LAN
10/100 BASE-T cross cable
Set a unique number to avoid doubling
Set the same domain
DHCP OFF
IP ADDRESS 192. 168. 100. 101
SUBNET MASK 255. 255. 255. 000
PROXY SERVER NO USE
DHCP SERVER NO USE
IP ADDRESS 192. 168. 100. 100
SUBNET MASK 255. 255. 255. 000
BR-DV6000
PROFESSIONAL MENU RESET A.DUB
EJECT
COUNTER AUDIO INPUT SELECT MONITOR OUTPUT REMOTE
LOCAL
CTL L MIX R
CH-1/2 MIX CH-3/4
DV LINE Y/C (CPN) TC
UB
REW STOP FF
REC
OPERATE
PLAY PAUSE DISP
SET SEARCH+
BLANK CUE UP HOLD
PHONES REC LEVEL
CH-1/3 CH-2/4
MIC
SEARCH–
Mini
* For the PC settings when using a LAN card,
refer to the instruction manual included with
the LAN card.
* Up to 10 clients can access at the same
time.
The SA-DV6000 supports wired LAN connections to client computers either locally, through an intranet or over the internet. Connecting
multiple VTR to a Client PC, or multiple Client PC to a VTR is supported. In addition, it is possible for a client to remotely control the VTR
as well.
A list of LAN card currently supported by the SA-DV6000 is shown on Page 4. Any compatible LAN card can be used in the Client PC.
For LAN card settings on the Client PC side, see the instruction manual of the Client PC or LAN card.
\ Wired Connections, Single VTR to Single Client PC
NOTE:
Refer to the appropriate manual for setting the LAN card or Client PC
Perform the following settings for the above configuration.
● DHCP should be OFF
2
● VTR and Client PC are set the same domain and different IP addresses.
● The Netmask of both the VTR and computer must be the same
● A CAT-5 cross cable is used between the VTR and computer
● Set the network connection of the Client PC to use no proxy server. Please refer to Page 27 for information regarding this setting if
troubles are encountered.
2 In case the connecting Client PC is not a server equipped with a DHCP feature.
