29
Using LAN card/LAN terminal
Recording to DV tape and Client PC Simultaneously
Set to TRIG
1.
Insert a LAN card into the Network Pack, or connect a LAN cable into the LAN
terminal.
2.
Turn on the BR-DV6000 power.
Check to see that the LAN card display is showing on the LCD screen. (When
using a LAN card)
3.
Select the input signal using the INPUT SELECT switch.
4.
Insert a recordable DV cassette tape.
5.
Press the MENU button to display the TOP MENU screen.
6.
Set the NETWORK PACK CONFIG menu screen.
q Set MPEG REC to “TRIG”.
w Set the video/audio compress in the ENCODE SETUP menu screen. ( ☞ page 8)
e When completed, press the MENU button to return to the normal screen.
7.
When pressing the REC and PLAY buttons of the BR-DV6000 with Streamproducer
or Streamcapture software operating in the Trigger more, recording to the DV
cassette tape and Client PC will start simultaneously.
(Hold down the REC button then press the PLAY button. If the PLAY button is
pressed first, the video may flicker momentarily.)
● The LAN card display on the LCD screen will be as follows:
e : Red display during data transmission. (When using a LAN card)
8.
To stop transmission or recording, press the PAUSE button.
● BR-DV6000 will be in the standby mode.
9.
To resume transmission or recording, press the PALY button.
10 .
To end operation, press the STOP button to stop transmission then disconnect
network connection. Then turn off the power.
Lastly, remove the LAN card.
Memo
● Streaming data will be sent from the LAN card or LAN terminal even when a DV
cassette tape is not inserted.
● When the DV cassette tape reaches the end during recording, the transmission
of streaming data from the LAN card/LAN terminal is also stopped.
LCD screen
LAN card display
CH1
NDF 12
H
34
M
34
S
10
F FREE
CH2
PLAY SP222 min
01/02/03
01:23:45
INS AM
OVER
48k
TC
L dB 0 10 20 30 40
OVER
W
Y/C
VA
SYNC
‰
e
CF
NETWORK PACK CONFIG
menu screen
NE T WOR K
OR T W E N K A CK P ON C I G F
E N CO DE
MPE G R EC
T R G I
MOV I E CL I P S
MENU R E S E T
PAGE B ACK
. .
. .
S E T
E T
P U
P U
T . . S E P U MA I N
( WMP u n d r 8 ) e
N CE L C A
( C F V i e w r ) e
TC 0 0 : 0 0 : 0 0 0 . 0
ENCODE SETUP menu screen
BR-DV6000
PROFESSIONAL
MENU RESET A.DUB
EJECT
COUNTER
AUDIO INPUT
SELECT MONITOR OUTPUT REMOTE
LOCAL
CTL L
MIX
R
CH-1/2
MIX
CH-3/4
DV
LINE
Y/C
(CPN)
TC
UB
REW STOP FF
REC
OPERATE
PLAY PAUSE DISP
SET SEARCH+
BLANK CUE UP HOLD
PHONES REC LEVEL
CH-1/3 CH-2/4
MIC
SEARCH–
Mini
PLAY button
PAUSE button
STOP button
INPUT SELECT switch
REC button MENU button
