10
Menu settings
Setting the NETWORK PACK menu screen
Menu screen settings can be made regardless of whether a card is inserted. Settings will be stored in the SA-DV6000 memory even
when turning the power off.
\ Settings are made by viewing the LCD screen or video monitor.
1.
Turn on the BR-DV6000 power.
2.
Press the MENU button. The TOP MENU screen appears.
3.
Press the DISP (6) or the BLANK (7) button, move the cursor (t) to NETWORK
PACK CONFIG and press the SET button or SEARCH+ (t) button.
● The NETWORK PACK CONFIG menu screen appears.
4.
Select the item to set.
Press the DISP (6) or the BLANK (7) button, move the cursor to the desired item
to set and press the SET button.
● The selected menu screen appears.
● When selecting MPEG REC or MENU RESET, the setting area flashes and the
setting can be changed. Set the item according to step 6.
● When selecting NETWORK MAIN SETUP, the network related setting screen
appears. ( ☞ page 11)
5.
Select an item within the menu screen.
Press the DISP (6) or the BLANK (7) button, move the cursor (t) to the desired
item to set and press the SET button.
● The setting area flashes and the setting can be changed.
6.
Change the setting.
Press the DISP (6) or the BLANK (7) button to change the setting and press the
SET button.
● Flashing of the setting area stops and the new setting is confirmed.
\ When changing multiple settings, repeat steps 5 and 6 above.
7.
Return to the TOP MENU screen.
Press the DISP (6) or the BLANK (7), move the cursor (t) to PAGE BACK and
press the SET button or SEARCH– (8) button.
8.
When quitting menu screen setting and returning to the normal screen, perform
one of the following operations.
● Press the MENU button.
● Move the cursor (t) to EXIT in the TOP MENU screen and press the SET
button.
● The NETWORK PACK CONFIG menu
screen will not appear during card initial-
ization (flashing display).
The NETWORK PACK CONFIG menu set-
tings cannot be changed when recording
to a CF Memory Card or transmitting data
via LAN.
TOP MENU screen
NETWORK MAIN SETUP menu screen
(
☞ page 11)
NETWORK PACK CONFIG
menu screen
Cursor
Setting
NE T WOR K T UP . . S E
OR T W E N K A CK P ON C I G F
E N CO DE
MPE G R EC
T R G I
MOV I E CL I P
MENU R E S E T C AN C E L
PAGE B ACK
T UP . . S E
T UP . . S E
MA N I
( WMP u n d e r 8 CF V i e w e r ) ( )
T C 0 0 : 0 0 : 0 0 0 . 0
OD NC E E E T S UP
F RAME S I Z E 3 2 0 x 2 4
B I T RA T E 3 8 4 k b /
MA X F RAME RA T E M I D
S T R E AM T Y P E for WMP
P AGE BACK
0
s
T C 0 0 : 0 0 : 0 0 0 . 0
Setting
S Y S T EM . .
M E N U
REMO T E . .
AU D I O . .
V I D E O . .
T C / U B / C L OCK . .
D I S P L A Y S E T . .
. .
E MO V I C L I P . .
NE TWOR K P AC K C ON F I G
E X I T
BR-DV6000
PROFESSIONAL
MENU RESET A.DUB
EJECT
COUNTER
AUDIO INPUT
SELECT MONITOR OUTPUT REMOTE
LOCAL
CTL L
MIX
R
CH-1/2
MIX
CH-3/4
DV
LINE
Y/C
(CPN)
TC
UB
REW STOP FF
REC
OPERATE
PLAY PAUSE DISP
SET SEARCH+
BLANK CUE UP HOLD
PHONES REC LEVEL
CH-1/3 CH-2/4
MIC
SEARCH–
Mini
MENU button
SET button
SEARCH– ( ) button
DISP ( ) button
BLANK ( ) button
SEARCH+ ( ) button
