- 8 -
Block Diagram
LGA775
Processor
CPU CLK+/-(333/266/200/133 MHz)
Host Interface
LPC BUS
IT8718
PCI CLK
(33 MHz)
3 PCI
PCI Bus
2 PCI Express x 1
PCI Express Bus
nVIDIA ®
nForce 650i
SLI
Northbridge
nVIDIA ®
nForce 650i
SLI
Southbridge
3 IEEE 1394a
TSB43AB23
DDRII 800/667/533 MHz DIMM
Dual Channel Memory
LAN
RJ45
Marvell 88E1
11
6
4 SATA 3Gb/s
8 USB
Ports
Line-Out
MIC
CODEC
Line-In
SPDIF In
SPDIF Out
Side Speaker Out
Center/Subwoofer Speaker Out
Surround Speaker Out
Floppy
PS/2 KB/Mouse
LPT Port
COM Port
ATA 33/66/100/133
IDE Channels
PCI Express x 16 Bus
2 PCIe x8 1 PCIe x16
or
Switch
PCIe CLK
(100 MHz)
SLI Mode Normal Mode
x 1 x 1
PCIe CLK
(100 MHz)
Dual BIOS
