GA-N650SLI-DS4 Motherboard
- 72 -
English
CMOS Setup Utility-Copyright (C) 1984-2007 Award Software
SATA-II RAID Config
Item Help
Menu Level
SATA-II RAID function
[Enabled]
SATA-II 1 Primary RAID
[Enabled]
SATA-II 1 Secondary RAID
[Enabled]
SATA-II 2 Primary RAID
[Disabled]
SATA-II 2 Secondary RAID
[Disabled]
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
CMOS Setup Utility-Copyright (C) 1984-2007 Award Software
Integrated Peripherals
SATA-II RAID Config
[Press Enter]
On-Chip IDE Channel0
[Enabled]
IDE DMA transfer access
[Enabled]
On-Chip MAC Lan
[Auto]
Onboard LAN Boot ROM
[Disabled]
On-Chip IDE Channel1
[Enabled]
NV Serial-ATA Controller
[All Enabled]
IDE Prefetch Mode
[Enabled]
On-Chip USB
[V1.1+V2.0]
USB Keyboard Support
[Disabled]
USB Mouse Support
[Disabled]
Onboard Audio Function
[Auto]
SMART LAN
[Press Enter]
Onboard 1394
[Enabled]
Legacy USB storage detect
[Enabled]
Onboard Serial Port 1
[3F8/IRQ4]
Onboard Parallel Port
[378/IRQ7]
Parallel Port Mode
[SPP]
x ECP Mode Use DMA
3
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
Item Help
Menu Level
Figure 1
To set up a RAID array, ensure that
SATA-II RAID function is enabled (Figure 2), otherwise leave it
disabled. Then enable the SATA channels with hard disks that you want to use for RAID (for example,
SATA-II 1 Primary RAID controls the SATAII0 connector and SATA-II 1 Secondary RAID controls the
SATAII1 connector) (Figure 2).
The BIOS Setup menus described in this section may not show the exact settings for your
motherboard. The actual BIOS Setup menu options you will see shall depend on the motherboard
you have and the BIOS version.
Figure 2
(2) Configuring SATA controller mode and boot sequence in BIOS Setup
Make sure to configure the SATA controller mode correctly in system BIOS Setup and set the first boot
device.
Step 1:
Turn on your computer and press Del to enter BIOS Setup during POST (Power-On Self Test). In the
example in Figure 1, make sure that NV Serial-ATA Controller under the Integrated Peripherals
menu is set to All Enabled or SATA-1, depending on which SATA connectors you connect. (SATA-1
controls the SATAII1 and SATAII0 connectors) If you wish to create RAID array, press ENTER on the
SATA-II RAID Config item to enter the submenu .
