GA-N650SLI-DS4 Motherboard Layout
KB_MS
CPU_FAN
LGA775
ATX
GA-N650SLI-DS4
USB
LAN
CD_IN
F_AUDIO
AUDIO
BACKUP BIOS
PCIE_16_1
F1_1394
PCIE_2
SPDIF_IN
DDRII1
DDRII2
DDRII3
DDRII4
F2_1394
BATTERY
F_PANEL
IT8718
SYS_FAN
SATAII0
ATX_12V_2X
nVIDIA
®
nForce 650i
SLI
nVIDIA
®
nForce 650i
SLI
PWR_LED
IDE1
PCI1
SATAII2
SATAII1 SATAII3
PCIE_16_2
PCI2
PCI3
USB
1394
CLR_CMOS
COMA
COAXIAL
OPTICAL
LPT
CODEC
Marvell
88E1116
PWR_FAN
IDE2
PCIE_1
TSB43AB23
F_USB2
F_USB1
PCIE_12V
FDD
SLI Switch Module Socket
MAIN BIOS
NB_FAN
CI
