Invacare Basic Tilt - Manual (Page 94)

T.R.C.M. Upgrade Kit w/ Mercury Free Switches
Tilt Only or Tilt/Recline & Recline Only
As of 7/1/2009, switches are mercury free.
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1025708 Bolt, Hex Head Cap (1/4-20 x 3/4") 1 2 1
1025729 Screw, Phillips Pan Head Tap (#8-32 x 3/8") 1 3 2
1025736 Locknut (1/4-20) 1 2 3
1079846-NLA NLA - Bracket, T.R.C.M. Controller Mounting, Black 1 1 4
1079017 Controller, MKIV T.R.C.M. 1 1 5
1080133-NLA NLA - Harness, Motor Actuator 1 1 6
1077519 Kit, 4-Way Switch Joystick Tube Mounting
Hardware 1 1 17 D
Bracket, Joystick Mounting, Black 1 1 7
Washer (#10 Flat) 1 2 8
Screw, Phillips Pan Head (#10-32 x 1/2") 1 2 9
Screw, Hex Head (1/4-20 x 1-1/8") 1 2 10
Half Clamp, Non-Threaded Holes 1 1 11
Half Clamp, Threaded Holes 1 1 12
1077520 Kit, 4-Way Switch Quad Link Mounting Hardware 1 1 17 E
Screw, Phillips Pan Head (#10-32 x 1/2") 1 2 7
Bracket, Quad Link Mounting, Black 1 1 8
Washer (#10 Flat) 1 2 9
Locknut (#10-32) 1 2 13
Screw, Phillips Pan Head (#10-32 x 1-3/8") 1 2 14
1139418 Kit, 4-Way Switch Quad Link Mounting Hardware 1 1 17 G
Locknut (#10-32) 1 2 13
Screw, Phillips Pan Head w/Patch (#10-32 x 7/8") 1 2 14
Screw, Phillips Pan Head (#10-32 x 1/2") 1 2 15
Washer, Nylon (#10) 1 2 16
1134132 Bracket, 4-Way Switch Quad Link, Black - Right 1 1 18
1134133 Bracket, 4-Way Switch Quad Link, Black - Left 1 1 18
1080116 Switch, 4-Way (FWT) 1 1 19
1020818 Switch, Red Flex Ribbon (Tape) Reset 1 1 20
1123276 Kit, Switch, Black Egg Reset w/ Hook/Loop
Adhesive Back Fastener & Attaching Screws
(EGSBLK) 1 1 20 F
1081400 Kit, T.R.C.M. Upgrade with Mercury Switches 1 1 21 A,A1,A
2,C
1080635 Harness, Recline/Tilt Limit Mercury Free Ball Switch 1 1 B
1080634 Harness, Drive Lockout Mercury Free Ball Switch 1 1 B
0309019-NLA NLA - Cover, Controller 1 1 B
0152400-NLA NLA - Tie Wrap, Black (8" L) 1 10 B
0154500-NLA NLA - Cable Tie, Black (4") 1 10 B
1081366-NLA NLA - Instruction Sheet, MKIV T.R.C.M. Upgrade 1 1 B
1043576 Service Manual, MKIV Electronics 1 1 B
93
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 96-194
