Genius Legrest
Tilt Only or Basic Recline 4XP or Tilt/Recline & Recline Only
NOTE: Mechanical elevation for Basic recline 4XP. Power elevation for Tilt Only and Tilt/Recline, Recline
Only.
Due to a change to the Legrest Calf Pad size made on 4/23/12, you must also order the hardware kit
(1109613) when ordering replacement Calf Pads.
Item
Number Part Number Description Note
Quantity Per
Package Assembly
Screw, Phillips Pan Head (#10-32 x 11/16") 1 2 36
Screw, Phillips Pan Head (#10-32 x 1") 1 2 36
Plate, Legrest Pad 1 1 37
Block, Mounting 1 1 38
Instruction Sheet, Legrest Pad Mtg. 1 1
8881091811 Pad, Calf - Right/Left 1 1 40 A,G
0238124 Tube, Legrest (18") 1 1 41
0232424 Tube, Legrest (20") 1 1 41
0177022 Clamp, Tube Half 1 2 42
0177602 Plate, Adjustment 1 2 43
1024793 Screw, Hex Head (1/4-20 x 1-3/4") 1 3 44
1096664 Plug Button, Black (1") 1 1 45
0177222 Pivot, Footplate 1 1 46
1027097 Plug Button, Black (3/4") 1 1 47
0194906 Screw, Phillips Pan Head Tap (#8-32 x 1/2") 1 1 48
0176022 Spacer 1 2 49 C
0186000 Spacer, Wheel 1 2 49 D
0179824 Tube, Footplate, Black 1 1 50 C
0288824-NLA NLA - Tube, Footplate, Black 1 1 50 D
1036120 Spring 1 2 51 C
1036123 Spring, Leaf 1 2 51 D
1043659 Footplate, Aluminum, Deluxe, Black - Right (8" W x
5-3/4" L) 1 1 52 C
1043660 Footplate, Aluminum, Deluxe, Black - Left (8" W x
5-3/4" L) 1 1 52 C
44200X025 Footplate, Aluminum, Extra Large, Black - Right (8"
W x 8-1/2" L) 1 1 52 D,E
44200X026 Footplate, Aluminum, Extra Large, Black - Left (8" W
x 8-1/2" L) 1 1 52 D,E
See Chart Genius Legrest 1 1 F
A - Items 39 and 40 must be ordered together in pairs for Genius Legrest manufactured before 11/20/01.
B - Includes items 27 and 33 - 38 and Instruction Sheet.
C - Standard Footplate with Rubber Edge
D - X-Large Footplates
E - Black Wrinkle Coat
F - Not Shown
G - Due to a change to the Legrest Calf Pad size made on 4/23/12, you must also order the hardware kit (1109613) when
ordering replacement Calf Pads.
NOTE:
116
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 96-194
