MAX Controller 5.7 S/N start at TE4000 & 4-Way Switch
Tilt/Recline & Recline Only
Item
Number Part Number Description Note
Quantity Per
Package Assembly
0282700-NLA NLA - Controller, MAX (5.7) 1 1 1
1081573 Controller, MAX 5.7 (For Upgrade Kit Only) 1 1 C,D
0139306-NLA NLA - Screw, Socket Button Head (#10-32 x 3/4") 1 2 2
0281300 Rivnut (#10-32 x 19/32") 1 2 2
0224806-NLA NLA - Washer (#10) 1 2 2
0018500-NLA NLA - Switch, Limit 1 1 3 A
0278600-NLA NLA - Harness, Actuator 1 1 4
0038100-NLA NLA - Box, Switch, Triple 1 1 5
0037900 Box, Switch, Double 1 1 5
0038000 Box, Switch, Single 1 1 5
1077304 Dual Lock, Male/ Female Adhesive Back (1" x 3") 1 1 6
0279800 Box, Four Way Switch 1 1 7
0278900-NLA NLA - Harness, Power, Storm, Round Plug 1 1 8
0018600 Switch, Limit - Molex Style 1 1 9 B
0200300-NLA NLA - Cable, Interface, Power Legs Combined 1 1 10
0015000 Cable, Interface, Power Legs Independent (1 or 2
Functions) 1 1 10
0014800 Cable, Interface, Invacare R.I.M. Control 1 1 10
0015400-NLA NLA - Cable, Interface, Peachtree Power Legs
Combined 1 1 10
1072695 Screw, Phillips Pan Head Tap (#6 x 1/2") 1 4 11
7930304 Screw, Socket Head (1/4-20 x 1-1/4") 25 3 12
317601 Locknut, Low Profile (#10-32) 1 2 13
0194602 Plate, Joystick Tube Mounting 1 1 14 F
0212002-NLA NLA - Plate, Quad Link Mounting 1 1 14 E
1077266 Mounting Plate Assembly, Joystick Tube 1 1 15 F
1077267 Mounting Plate Assembly, Quad Link 1 1 15 E
A - Tilt and Recline
B - Drive Lockout
C - Max Controller 5.7 is used only when the power and actuator "Adaptor Cables" are present.
D - Not Shown
E - Use with Quad Link before 4/07/06
F - Use with Joystick Tube and Quad Link (QLA) after 4/06/06 NOTE:
88
