Invacare Basic Tilt - Manual (Page 42)

A.B.S. Curved Back Assembly
Recline, Fixed Back (Non-VSR)
Tilt/Recline and Recline Only
Item
Number Part Number Description Note
Quantity Per
Package Assembly
0029002 Bracket, Non-Sliding Back Pan Mounting 1 4 1
7930323 Package, Locknut (1/4-20) 25 4 2
1029545 Screw, Socket Flat Head (1/4-20 x 3/4") 1 4 3
See Chart #'s 4-7 A.B.S. Curved Back Assembly 1 1 4-7
1125723 Kit, Hook Fastener w/ Adhesive Back 1 1 A,E
0143900 Flap, Back Pan - Tarsys 1 1 A,B
0144000 Flap, Back Pan - Tarsys 1 1 A,C
0144100 Flap, Back Pan - Tarsys 1 1 A,D
A - Not Shown.
B - 16"-17" Wide
C - 18"-19" Wide
D - 20"-24" Wide
E - Hook Fastener Adhesive Kit is used to attach the Back Cover to the Back Pan and must be ordered when a new Back Pan
or Back Assembly is requested.
NOTE:
Material
Back
Width x Height
Overall
Back Height
Item #4
1" Back Pan
Item #5
Back Foam
Item #6
Back Assembly
Cover
Item #7
w/Fixed Hardware
1077087 1073093 1073071 1073064-NLA 20"-22"H 14" x 18"
1077088-NLA 1077077 1073081 1073065 20"-22"H 15" x 18"
1072868-NLA 0124321 0010120 0118819 20"-22"H 16" x 18"
1072869 0124421 0126720 0118919 20"-22"H 17" x 18"
1072870 0124521 0126820 0119019 20"-22"H 18" x 18"
1072871-NLA 0124621 0126920 0119119 20"-22"H 19" x 18"
1072872-NLA 0124721 0010220 0119219 20"-22"H 20" x 18"
1077089-NLA 0304121 1073083-NLA 0119319 20"-22"H 21" x 18"
1077090 0304321 1073084-NLA 0119419 20"-22"H 22" x 18"
Special Special Special Special 20"-22"H 23" x 18"
Special Special Special Special 20"-22"H 24" x 18"
1077091-NLA 0010921 1073073 1073066 23"-25"H 14" x 20"
1077092 0011121 1073086 1073067-NLA 23"-25"H 15" x 20"
1072873 0011321 0009820 0125319-NLA 23"-25"H 16" x 20"
1072874-NLA 0011521 0010020 0125419-NLA 23"-25"H 17" x 20"
1072875 0011721 0010220 0125519 23"-25"H 18" x 20"
1072876 0011921 0010420 0125619 23"-25"H 19" x 20"
1072877 0012121 0010620 0125719 23"-25"H 20" x 20"
41
