A.B.S. Curved Back Assembly
Recline, Sliding Back (VSR)
Tilt/Recline and Recline Only
Item
Number Part Number Description Note
Quantity Per
Package Assembly
0047800 Block, Glide 1 4 1
0052906 Screw, Socket Button Head (1/4-20 x 3/4") 1 4 2
See Chart #'s 3-6 A.B.S. Curved Back Assembly 1 1 3-6
1125723 Kit, Hook Fastener w/ Adhesive Back 1 1 A,E
0143900 Flap, Back Pan - Tarsys 1 1 A,B
0144000 Flap, Back Pan - Tarsys 1 1 A,C
0144100 Flap, Back Pan - Tarsys 1 1 A,D
A - Not Shown
B - 16"-17" Wide
C - 18"-19" Wide
D - 20"-24" Wide
E - Hook Fastener Adhesive Kit is used to attach the Back Cover to the Back Pan and must be ordered when a new Back Pan
or Back Assembly is requested.
NOTE:
Material
Back
Width x Height
Overall
Back Height
Item #3
Back Pan
Item #4
1" Back Foam
Item #5
Back Cover
Item #6
Back Asbly
w/Sliding Hdwr
1077095 1073089 1073068 0128819 21"-22"H 14" X 14"
1077096-NLA 1073090 1073069 0128919-NLA 21"-22"H 15" x 14"
1077097 0124821 1073070 0129019-NLA 21"-22"H 16" x 14"
1077098 0124921 0310820 0129119 21"-22"H 17" x 14"
1077099 0125021 1073071 0129219-NLA 21"-22"H 18" x 14"
1077100-NLA 0125121 1073072-NLA 0129319-NLA 21"-22"H 19" x 14"
1077101 0125221 1073073 0129419 21"-22"H 20" x 14"
1077102 1073091 1073074 0129519 21"-22"H 21" x 14"
1077103 1073092 1073075 0129619 21"-22"H 22" x 14"
Special Special Special Special 21"-22"H 23" x 14"
Special Special Special Special 21"-22"H 24" x 14"
1077104-NLA 0010821 1073070 0048819 23"-25"H 14" x 16"
1077105-NLA 0011021 1073077 0048919-NLA 23"-25"H 15" x 16"
1072878 0011221 0009720 0049019 23"-25"H 16" x 16"
1072879 0011421 0009920 0049119 23"-25"H 17" x 16"
44
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 96-194
