Invacare Basic Tilt - Manual (Page 18)

Seat Frame Attaching Hardware
Tilt/Recline and Recline Only
Item
Number Part Number Description Note
Quantity Per
Package Assembly
0055800 Washer, Nylon (7/16 x 3/4 x 3/32") 1 6 1
0060300 Bushing, Bronze (5/16 x 7/16 x 1-1/4") 1 2 2
0115102-NLA NLA - Plate, Seat Frame Inner Mounting - Right 1 2 3
0115202-NLA NLA - Plate, Seat Frame Inner Mounting - Left 1 2 3
0115302-NLA NLA - Plate, Seat Frame Outer Mounting - Right 1 1 4
0115402-NLA NLA - Plate, Seat Frame Outer Mounting - Left 1 1 4
0190102-NLA NLA - Bracket, Connector, Black 1 1 5
0143205-NLA NLA - Locknut, Low Profile (#6-32) 1 2 6
313229-NLA NLA - Screw, Phillips Pan Head (#6-32 x 1/2") 1 2 7
0115502 Link, Mounting Plate, Black 1 1 8
0055800 Washer, Nylon (7/16 x 3/4 x 3/32") 1 11 9
0140306-NLA NLA - Screw, Hex Head (3/8-16 x 4-1/2") 1 2 10
0140206 Screw, Hex Head (3/8-16 x 3-1/2") 1 1 11
0118524 Link, Tilt 1 2 12
0054106 Locknut, High Profile (3/8-16) 1 5 13
0139606 Screw, Hex Head (5/16-18 x 1") 1 2 14
0054906 Locknut, High Profile (5/16-18) 1 1 15
1072692 Lockwasher, Split (5/16") 1 4 16
0139806 Screw, Hex Head (5/16-18 x 3") 1 1 17
7930333 Locknut (1/4-20) 25 6 18
0050406 Washer, Flat (1/4 x 5/8 x 1/16") 1 12 19
0115024-NLA NLA - Bar, Mounting 1 2 20
0140406 Screw, Socket Head, Cap (5/16-18 x 1-1/2") 1 2 21
0052306-NLA NLA - Screw, Hex Head (1/4-20 x 2-1/4") 1 5 22
0055506 Screw, Button Head, Socket (5/16-18 x 2") 1 2 23
0115624 Link, Tilt, Black - Upper 1 2 24
0120300 Bushing (3/8 x 1/2 x 7/8") 1 4 25
1106223 Screw, Socket Head (3/8-16 x 2-1/2") 1 1 26
0140006 Washer, Steel (13/32 x 5/8 x 1/32") 1 4 27
0140206 Screw, Hex Head (3/8-16 x 3-1/2") 1 1 28
0120100 Bushing (3/8 x 1/2 x 3/4") 1 4 29
0115724 Link, Tilt, Black - Lower 1 2 30
0140600 Washer, Rubber (13/16 x 13/32 x 3/32) 1 2 31
0140506-NLA NLA - Screw, Socket Head w/ Thread Lock (5/16-18
x 1") 1 2 32
1072747 Plates, Seat Frame Mounting w/ Hardware 1 1 33
1072810-NLA NLA - Hardware, Seat Frame Mounting 1 1 34 A
1072809 Hardware, Seat Frame Mounting 1 1 35 B
1077357-NLA NLA - Pin, Roll (3/16 x 1-1/8" Long) 1 1 36
0211102 Stop, Tilt, Black 1 1 37
1077358 Lockwasher, Split (3/8-16) 1 1 38
1077359 Nut, Hex (3/8-16) 1 1 39
0225100-NLA NLA - Bumper, Tilt 1 1 40
17
