S.F.T. Switch w/ Drive Lockout & DAD Box
(Before 1/18/99)
Basic Tilt Only
Item
Number Part Number Description Note
Quantity Per
Package Assembly
0012700 D.A.D. Box with Tilt Harness 1 1 1
0227700 Harness, Power, Storm 1 1 2
0018500-NLA NLA - Switch, Limit 1 1 3 F
See Note See Footnote 1 1 4
1077305 Drive Lockout Mounting Hardware - Tilt System 1 1 5 E
0020122-NLA NLA - Mounting Plate 1 1 5
1072695 Screw, Phillips Pan Head Tap (#6 x 1/2") 1 2 5
0139606 Screw, Hex Head (5/16-18 x 1") 1 1 5
1072692 Lockwasher, Split (5/16") 1 1 5
0037400 Switch, S.F.T. 1 1 6 A
0224202 Plate, S.F.T. Switch, Joystick Tube Mounting 1 1 7 K
0224702 Plate, S.F.T. Switch, Quad Link Mounting 1 1 7 J
0225402-NLA NLA - Plate, D.A.D. Box, Joystick Tube Mounting 1 1 7 K
0225602 Plate, D.A.D. Box, Quad Link Mounting 1 1 7 J
313329 Screw, Phillips Pan Head (#6-32 x 1/2") 1 2 8 D
7930304 Screw, Socket Head (1/4-20 x 1-1/4") 25 3 9
317601 Locknut, Low Profile (#10-32) 1 2 10
0224806-NLA NLA - Washer (#10) 1 2 11
0067106-NLA NLA - Screw, Phillips Pan Head (#10-32 x 1/2") 1 2 12
1077270 Mounting Plate Assembly, S.F.T. Switch, Joystick
Tube 1 1 13 K
1077271 Mounting Plate Assembly, S.F.T. Switch, Quad Link 1 1 13 J
1077268 Mounting Plate Assembly, D.A.D. Box, Joystick
Tube 1 1 13 K
1077269 Mounting Plate Assembly, D.A.D. Box, Quad Link 1 1 13 J
0238800-NLA NLA - Switch, Limit Override (DAD Box) 1 1 14
1077405-NLA NLA - Harness, Dual Actuator (DAD Box) 1 1 15
0014800 Cable, Interface, Invacare R.I.M. Control 1 1 C,G
0200300-NLA NLA - Cable, Interface, Power Legs Combined 1 1 C,G
1082364 Basic Tilt DAD Relay Controller Upgrade Assembly 1 1 C,H
1084172 Basic Tilt DAD Relay Controller Upgrade Assembly 1 1 C,I
1084706 Package, Decals, D.A.D. Relay Controller Upgrade 5 1 B,C
A - Old style S.F.T. switch doesn't have the drive lockout feature built in.
B - Decal package is supplied in all upgrade kits and covers all systems. Decals not sold separately. Decals are labeled "Tilt,"
"Recline," "Drive Lockout," "PLeg" and "caution While Propelling."
C - Not Shown
D - Joystick Tube Mounting Plate uses 4 each per assembly and the Quad Link Mounting Plate uses 2 each per assembly.
Both use 1 each quantity per package.
E - Part numbers 0020122, 1072695, 0139606, and 1072692 are available for individual sale.
F - Drive Lockout
G - IDAD Box Only
H - Before 1/18/99 (Includes Items 1, 7, 9-12, and 14)
I - After 1/17/99 (Includes Items 1-5, 7, 9-12, and 14)
J - Use with Quad Link before 4/07/06
K - Use with Joystick Tube and Quad Link (QLA) after 4/06/06
NOTE:
72
