Profile Back Assembly
Fixed, Non-VSR
Tilt/Recline and Recline Only
Item
Number Part Number Description Note
Quantity Per
Package Assembly
See Chart #'s 1-4 Profile Back Assembly (Fixed, Non-VSR) 1 1 1-4
0052906 Screw, Socket Button Head (1/4-20 x 3/4") 1 4 5 B
0051206-NLA NLA - Screw, Machine, Hex Socket, Button Head
(1/4-20 x 1-1/4) 1 4 5 C
0190500-NLA NLA - Block, Glide (16", 18" and 20" Wide) 1 4 6
0190600-NLA NLA - Block, Glide (17" and 19" Wide) 1 4 6
0050100 Washer, Nylon Flat (1/4 x 1/2 x 1/16") 1 4 7
7930304 Screw, Socket Head (1/4-20 x 1-1/4") 25 2 8
0226500-NLA NLA - Knob, Tee 1 2 9
0143900 Flap, Back Pan - Tarsys 1 1 A,D
0144000 Flap, Back Pan - Tarsys 1 1 A,E
0144100 Flap, Back Pan - Tarsys 1 1 A,F
A - Not Shown
B - 16"/18"/20" Wide
C - 17"/19" Wide
D - 16"-17" Wide
E - 18"-19" Wide
F - 20" Wide NOTE:
51
