A.B.S. Curved Back Assembly
Basic Tilt & Tilt Only
NOTE: Hook Fastener Adhesive Kit must be ordered when a Back Pan or Back Assembly is requested.
This will allow the Loop Fastener Adhesive on the Back Cover to attach properly.
Item
Number Part Number Description Note
Quantity Per
Package Assembly
0124202 Hook, Back Assembly Mounting 1 4 1
7930333 Locknut (1/4-20) 25 4 2
1029545 Screw, Socket Flat Head (1/4-20 x 3/4") 1 4 3
See Chart #'s 4-7 A.B.S. Curved Back Assembly 1 1 4-7
1125723 Kit, Hook Fastener w/ Adhesive Back 1 1 A,E
0143900 Flap, Back Pan - Tarsys 1 1 A,B
0144000 Flap, Back Pan - Tarsys 1 1 A,C
0144100 Flap, Back Pan - Tarsys 1 1 A,D
A - Not Shown
B - 16"-17" Wide
C - 18"-19" Wide
D - 20"-24" Wide
E - Hook Fastener Adhesive Kit is used to attach the Back Cover to the Back Pan and must be ordered when a new Back Pan
or Back Assembly is requested.
NOTE:
Material
Back
Width x Height
Overall
Back Height
Item #4
1" Back Pan
Item #5
Back Foam
Item #6
Back Assembly
Cover
Item #7
w/ Fixed
Hardware
1073098 0010821 1073070 0048819 18"-19"H 14" x 16"
1073099 0011021 1073077 0048919-NLA 18"-19"H 15" x 16"
1072790 0011221 0009720 0049019 18"-19" H 16" x 16"
1072791 0011421 0009920 0049119 18"-19"H 17" x 16"
1072792-NLA 0011621 0010120 0049219-NLA 18"-19"H 18" x 16"
1072793 0011821 0010320 0049319 18"-19"H 19" x 16"
1072794-NLA 0012021 0009820 0049419 18"-19"H 20" x 16"
1073100 0304021 1073078 0049519-NLA 18"-19"H 21" x 16"
1073101 0164421 1073079 0049619 18"-19"H 22" x 16"
Special Special Special Special 18"-19"H 23" x 16"
Special Special Special Special 18"-19"H 24" x 16"
1073102 1073093 1073071 1073064-NLA 20"-22"H 14" x 18"
1073103 1077077 1073081 1073065 20"-22"H 15" x 18"
1072795 0124321 0010120 0118819 20"-22"H 16" x 18"
1072796 0124421 0126720 0118919 20"-22"H 17" x 18"
1072797 0124521 0126820 0119019 20"-22"H 18" x 18"
1072798 8881024621 0126920 0119119 20"-22"H 19" x 18"
1072799 0124721 0010220 0119219 20"-22"H 20" x 18"
1073104-NLA 0304121 1073083-NLA 0119319 20"-22"H 21" x 18"
1073105 0304321 1073084-NLA 0119419 20"-22"H 22" x 18"
Special Special Special Special 20"-22"H 23" x 18"
Special Special Special Special 20"-22"H 24" x 18"
36
