Invacare Basic Tilt - Manual (Page 91)

T.R.C.M. & 4-Way Switch
Tilt Only or Tilt/Recline & Recline Only
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1025708 Bolt, Hex Head Cap (1/4-20 x 3/4") 1 2 1
1025729 Screw, Phillips Pan Head Tap (#8-32 x 3/8") 1 3 2
1025736 Locknut (1/4-20) 1 2 3
1079846-NLA NLA - Bracket, T.R.C.M. Controller Mounting, Black 1 1 4
0139606 Screw, Hex Head (5/16-18 x 1") 1 2 5
1072692 Lockwasher, Split (5/16") 1 2 6
1079017 Controller, MKIV T.R.C.M. 1 1 7
1080133-NLA NLA - Harness, Motor Actuator 1 1 8
0065706 Screw, Phillips Pan Head Tap (#10-16 x 3/4") 1 2 9
1077764-NLA NLA - Cover, Potentiometer Mounting Bracket 1 1 10
1079272-NLA NLA - Lever, Arm, Black 1 1 11
1025275 Screw, Set w/ Patch (#8-32 x 1/4") 1 1 12
1079991 Recline Potentiometer w/ Harness, Nut and Washer 1 1 13
1079992 Potentiometer, Tilt w/ Harness, Nut and Washer 1 1 13
1079278 Plate, Back 1 1 14
1017766-NLA NLA - Screw, Phillips Pan Head (4-40 x 1/4") 1 4 15
1017766-NLA NLA - Screw, Phillips Pan Head (4-40 x 1/4") 1 1 16
1079276 Plate, Front 1 1 17
1017423 Screw, Slotted Hex Washer Head w/ Patch (#10-32
x 1/2") 1 1 18
1079274 Stud, Mounting 1 1 19
1077519 Kit, 4-Way Switch Joystick Tube Mounting
Hardware 1 1 29 A
Bracket, Joystick Mounting, Black 1 1 20
Washer (#10 Flat) 1 2 21
Screw, Phillips Pan Head (#10-32 x 1/2") 1 2 22
Screw, Hex Head (1/4-20 x 1-1/8") 1 2 23
Half Clamp, Non-Threaded Holes 1 1 24
Half Clamp, Threaded Holes 1 1 25
1077520 Kit, 4-Way Switch Quad Link Mounting Hardware 1 1 29 B
Bracket, Quad Link Mounting, Black 1 1 20
Washer (#10 Flat) 1 2 21
Screw, Phillips Pan Head (#10-32 x 1/2") 1 2 22
Locknut (#10-32) 1 2 26
Screw, Phillips Pan Head (#10-32 x 1-3/8") 1 2 27
1139418 Kit, 4-Way Switch Quad Link Mounting Hardware 1 1 29 D
Screw, Phillips Pan Head (#10-32 x 1/2") 1 2 22
Locknut (#10-32) 1 2 26
Screw, Phillips Pan Head w/Patch (#10-32 x 7/8") 1 2 27
Washer, Nylon (#10) 1 2 28
1134132 Bracket, 4-Way Switch Quad Link, Black - Right 1 1 30
1134133 Bracket, 4-Way Switch Quad Link, Black - Left 1 1 30
1080116 Switch, 4-Way (FWT) 1 1 31
90
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 96-194
