Invacare Basic Tilt - Manual (Page 76)

S.F.T. Switch w/ Drive Lockout & DAD Box
(Before 1/18/99)
Basic Recline (4XP)
Item
Number Part Number Description Note
Quantity Per
Package Assembly
0012600-NLA NLA - D.A.D. Box with Recline Harness 1 1 1
0227700 Harness, Power, Storm 1 1 2
0018500-NLA NLA - Switch, Limit 1 1 3 G
See Note See Footnote 1 1 4 K
1077304 Dual Lock, Male/ Female Adhesive Back (1" x 3") 1 1 5
0037400 Switch, S.F.T. 1 1 6 A
0224202 Plate, S.F.T. Switch, Joystick Tube Mounting 1 1 7 J
0224702 Plate, S.F.T. Switch, Quad Link Mounting 1 1 7 I
0225402-NLA NLA - Plate, D.A.D. Box, Joystick Tube Mounting 1 1 7 J
0225602 Plate, D.A.D. Box, Quad Link Mounting 1 1 7 I
313329 Screw, Phillips Pan Head (#6-32 x 1/2") 1 1 8 C
7930304 Screw, Socket Head (1/4-20 x 1-1/4") 25 3 9
317601 Locknut, Low Profile (#10-32) 1 2 10
0224806-NLA NLA - Washer (#10) 1 2 11
0067106-NLA NLA - Screw, Phillips Pan Head (#10-32 x 1/2") 1 2 12
1077270 Mounting Plate Assembly, S.F.T. Switch, Joystick
Tube 1 1 13 J
1077271 Mounting Plate Assembly, S.F.T. Switch, Quad Link 1 1 13 I
1077268 Mounting Plate Assembly, D.A.D. Box, Joystick
Tube 1 1 13 J
1077269 Mounting Plate Assembly, D.A.D. Box, Quad Link 1 1 13 I
0238800-NLA NLA - Switch, Limit Override (DAD Box) 1 1 14
0014800 Cable, Interface, Invacare R.I.M. Control 1 1 D,H
0200300-NLA NLA - Cable, Interface, Power Legs Combined 1 1 D,H
0190000-NLA NLA - 4XP DAD Relay Controller Upgrade
Assembly 1 1 D,E
1084173-NLA NLA - 4XP DAD Relay Controller Upgrade
Assembly 1 1 D,F
1084706 Package, Decals, D.A.D. Relay Controller Upgrade 5 1 B,D
A - Old Style S.F.T. switch doesn't have the drive lockout feature built in.
B - Decal package is supplied in all upgrade kits and covers all systems. Decals not sold separately. Decals are labeled "Tilt,"
"Recline," "Drive Lockout," "PLeg" and "Caution While Propelling."
C - Joystick Tube Mounting Plate uses 4 each per assembly and the Quad Link Mounting Plate uses 2 each per assembly.
Both use 1 each quantity per package.
D - Not Shown.
E - Before 1/18/99 (Includes items 1, 7, 9-12 and 14)
F - After 1/17/99 (Includes items 1-5, 7, 9-12 and 14)
G - Drive Lockout
H - DAD Box Only
I - Use with Quad Link before 4/07/06
J - Use with Joystick Tube and Quad Link (QLA) after 4/06/06
K - Part is no longer serviceable in the field.
NOTE:
75
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 96-194
