LAN RJ45 Connector (CN10)
The SBC-370 is equipped with a built-in 10/100Mbps Ethernet Controller. You can
connect it to your LAN through the RJ45 LAN connector. For the location of this
connector, refer to figure 2.
Pin Number
Description
1
TX+
2
TX-
3.
RX+
4.
75
W
termination
5.
75
W
termination
6.
RX-
7.
75
W
termination
8.
75
W
termination
LED Connector for LAN (CN5)
For the location of this connector, refer to figure 2.
Pin Number
Description
1
VCC
2
LAN ACT.
Fan Connector (CN13/CN14/CN15)
The SBC-370 provides one CPU cooling fan connector and two system fan connec-
tors. These connectors can supply 12V/500mA (maximum) to the cooling fan. The
connector has a rotation pin that supplies the fan's rotation signal to the system
so that the system BIOS can read the fan speed. For the location of each connec-
tor, refer to figure 2.
•
CN13: CPU Fan Connector
•
CN14: System1 Fan Connector
•
CN15: System2 Fan Connector
Pin Number
Description
1
Fan Sensor
2
+12V
3
GND
23
Board Configuration
