Keyboard/Mouse Connector (CN8/CN17/CN18)
The SBC-370 provides one external keyboard, one external mouse, and one PS/2
keyboard and mouse connector.
• CN8: 5-pin Header External Keyboard Connector (see note below)
Pin Number Description
1 KB CLK
2 KB DATA
3 NC
4 GND
5 +5V
• CN17: PS/2 Mouse 5-pin Header Connector
Pin Number Description
1 MS DATA
2 NC
3 GND
4 +5V
5 MS CLK
• CN18: 6-pin Mini-DIN PS/2 Keyboard and Mouse Connector (see note below)
Pin Number Description
1 KB DATA
2 NC
3 GND
4 +5V
5 KB CLK
6 NC
For the location of these connectors, refer to figure 2.
Note: A keyboard cannot be connected to CN8 and CN18 simultaneously. A mouse can-
not be connected to CN17 and CN18 simultaneously. One of each device can be con-
nected to CN18 via a Y adapter cable) or CN8 and CN17.
