Parallel Port (CN4)
This port is usually connected to a printer. The SBC-370 includes an onboard par-
allel port accessed through a 26-pin flat-cable connector. For the location of this
connector, refer to CN4 in figure 2.
Pin Number Description
1 STROBE#
2 DATA 0
3 DATA 1
4 DATA 2
5 DATA 3
6 DATA 4
7 DATA 5
8 DATA 6
9 DATA 7
10 ACKNOWLEDGE
11 BUSY
12 PAPER EMPTY
13 PRINTER SELECT
14 AUTO FORM FEED #
15 ERROR#
16 INITIALIZE
17 PRINTER SELECT LN#
18 GND
19 GND
20 GND
21 GND
22 GND
23 GND
24 GND
25 GND
26 NC
Board Configuration 18
