External Switches and Indicators (CN7)
There are several external switches and indicators for monitoring and controlling
the CPU board. All the functions are in the CN7 Multi Panel connector. For the lo-
cation of this connector, refer to figure 2.
USB Port Connector (CN9)
The SBC-370 has two built-in USB ports for future I/O bus expansion. Pins 1, 3, 5,
and 7 for USB 0. Pins 2, 4, 6, and 8 for USB 1. For the location of this connector,
refer to figure 2.
Pin Number Description
1 VCC
3 SBD0-
5 SBD0+
7 GND
2 GND
4 SBD1+
6 SBD1-
8 VCC
21 Board Configuration
Pin Number Description
1 SPEAKER
2 VCC
3 NC
4 NC
5 NC
6 GND
7 +5V
8 KEYLOCK
9 RESET SW
10 GND
Pin Number Description
11 GND
12 GND
13 IDE LED
14 NC
15 +5V
16 ATX POWER CONTROL
17 ATX POWER BUTTON
18 ATX 5VSB
19 ATX 5VSB
20 ATX 5VSB
