536EX Chipset Developer’s Manual 61
Intel Confidential
Error Correction and Data Compression
+DS44=m
3, 0, 0,
471,
942,
140,
140,
1884,
3768
V.44 Data Compression: This command controls the V.44 data compression function if provided in the
DCE. It accepts the following sub parameters:
m=[[,[,[,[,
[,[,[,[,]]]]]]]]]
specifies the desired direction(s) of operation of the data compression function.
0 Negotiated… no compression
1 Transmit only
2 Receive only
3 Both directions, accept any direction
specifies whether or not the DCE should continue to operate if the desired
result is not obtained.
0 Do not disconnect if Rec. V.44 is not negotiated by the remote DCE as specified in
. Always set to 0.
specifies the use of stream method, packet method, multi-packet method.
0 Stream method
1 Packet method
2 Multi-packet method
specifies the maximum number of codewords which should be negotiated in the
transmit direction.
256 to 65536
specifies the maximum number of codewords which should be negotiated in the
receive direction.
256 to 65536
specifies the maximum string length to be negotiated in the transmit direction.
32 to 255
specifies the maximum string length to be negotiated in the receive direction.
32 to 255
specifies the maximum size of the history buffer to be negotiated in the transmit
direction.
≥ 512
specifies the maximum size of the history buffer to be negotiated in the receive
direction.
≥ 512
+EFCS=m 0
32-bit Frame Check Sequence: Controls the use of 32-bit frame check sequence option in V.42.
0 Use 16-bit FCS
1 Use 32-bit FCS if available in remote DCE; otherwise use 16-bit FCS
2 Use 32-bit FCS if available in remote DCE; otherwise disconnect
Table 21. V.44/V.42/V.42 bis and MNP Data Modem Command Descriptions (Continued)
Command Default Description
NOTE: An asterisk (*) denotes the factory-default setting.
