536EX Chipset Developer’s Manual 49
Intel Confidential
Data Mode AT COMMANDS
0, 0, 1,
, 0, 0,
0,
Synchronous Access Mode Configuration: controls the manner of operation of the Synchronous Access
Mode in the DCE (if present).
Syntax:
+ESA=[[,[,[,[,[,[,[,n2>]]]]]]]]
specifies the bit sequence transmitted by the DCE when a transmit data buffer underrun
condition occurs, while operating in Transparent sub-Mode.
0 In Transparent sub-Mode, DCE transmits 8-bit SYN sequence on idle. DCE receiver does
not hunt for synchronization sequence
1 In Transparent sub-Mode, DCE transmits 8-bit SYN sequence on idle. DCE receiver hunts
for 8-bit SYN sequence
2 In Transparent sub-Mode, DCE transmits 16-bit SYN sequence on idle. DCE receiver hunts
for 16-bit SYN sequence
specifies the bit sequence transmitted by the DCE when a transmit data buffer underrun
condition occurs immediately after a flag, while operating in Framed sub-Mode.
0 In Framed sub-Mode, DCE transmits HDLC flags on idle
1 In Framed sub-Mode, DCE transmits marks (ones) on idle
specifies the actions undertaken by the DCE when a transmit data buffer underrun or
overrun condition occurs immediately after a non-flag octet, while operating in Framed sub?Mode.
0 In Framed sub-Mode, DCE transmits abort on underrun in middle of frame
1 In Framed sub-Mode, DCE transmits a flag on underrun in middle of frame, and notifies
DTE of underrun or overrun
specifies whether or not, in V.34 half duplex operation, additional procedures besides those
specified in clause 12/V.34 shall be performed by the DCE when switching from primary channel to
secondary channel operation, and vice versa.
0 When switching between primary and secondary channel operation in V.34 half duplex, the
DCE only executes those procedures defined in clause 12/V.34
1 When switching between primary and secondary channel operation in V.34 half duplex, the
DCE executes additional procedures as described in 8.8.5 besides those defined in clause
12/V.34
specifies the CRC polynomial used while operating in Framed sub-Mode.
0 CRC generation and checking disabled
1 In Framed sub-Mode, the 16-bit CRC specified in 8.1.1.6/V.42 is generated by the DCE in
the transmit direction, and checked by the DCE in the receive direction
2 In Framed sub-Mode, the 32-bit CRC specified in 8.1.1.6/V.42 is generated by the DCE in
the transmit direction, and checked by the DCE in the receive direction
specifies if Non Return to Zero Inverted (NRZI) encoding is to be used by the DCE for transmit
and receive data.
0 NRZI encoding and decoding disabled
1 NRZI encoding enabled in the DCE in the transmit direction, and NRZI decoding enabled in
the DCE in the receive direction
specifies the octet value(s) to be used while performing character-oriented framing.
0–255 When =0, specifies the 8-bit transmit idle sequence to be used by the DCE.
When =1, specifies the 8-bit synchronization sequence to be used by the DCE.
When =2, specifies first 8 bits of 16-bit synchronization sequence to be used
by the DCE
specifies the octet value(s) to be used while performing character-oriented framing.
0–255 When =2, specifies last 8 bits of 16-bit synchronization sequence to be used
by the DCE
Table 18. Data Mode Command Descriptions (Continued)
Command Default Description
NOTE: An asterisk (*) denotes the factory-default setting.
