536EX Chipset Developer’s Manual

29

Intel Confidential

Data Mode AT COMMANDS

3.4

Modem Identification Commands [In, +FMI, +FMR,
+FMM, +GMI, +GMM, +GMR, +GSN,
+FMFR?, +FMDL?, +FREV?]

The modem provides product identification AT commands that help determine the modem’s
manufacturer, model number, and product revision. To provide flexibility with older software
application programs, the modem supports several commands that can be used to request a single
item of identification (such as a modem model number).

Table 15

lists the commands used to

obtain product information (all identification commands are usable in data, fax, or voice mode).

Example:

ATI1

Causes the modem to send the modem’s name to the DTE.

Intel 536EP

Response to the modem name request.

V.92 Modem

3.5

Establishing a Modem Connection [A, D, DS = n, S0]

Data mode provides several methods for establishing a connection with a remote modem. For each
modem, a connection can be initiated manually or automatically in both answer and originate
modes. A manual-to-manual connection is useful when both modems (that are on-hook) are
connected to an off-hook telephone line. For example, if two people are talking on the telephone,
they can manually establish a modem connection without first hanging up. When establishing a
manual connection, one modem must be designated as the originating modem and the other as the
answering modem. Manual originate mode is initiated by sending an ATD to the DCE. Manual
answer mode is accomplished by sending an ATA to the DCE.

Automatic originate mode is initiated by sending an ATD
or ATDS=m to the DCE. Automatic-answer mode is accomplished by setting S-register S0 to a
non-zero value. S1 keeps track of how many ring signals are detected. If the content of S0 is non-
zero and the number of ring signals (as defined by S0) are detected (that is, S1 = S0), then the DCE
goes off-hook and attempts to connect to the remote modem (with the following exceptions):

The time period between the ring signals is greater than 8 seconds, which causes the S1
counter to reset and thus never reach the value for S0.

Caller ID is enabled and S0=1, the modem answers on the second ring signal instead of the
first ring signal. This happens because Caller ID puts a signal on the telephone line between
the first and second ring signal.

Example:

Table 15. Product Identification Information

AT Commands

Product Information

ATIn Command

Data Mode

Class 1 Fax Mode

Legacy Modems

Modem Manufacturer

ATI2

AT+GMI

AT+FMI

AT+FMFR?

Model ID

ATI1

AT+GMM

AT+FMM

AT+FMDL?

Revision Number

ATI4

AT+GMR

AT+FMR

AT+FREV?
