BDM-610000049 Rev G Chapter 3: Connecting the cpuModule 45
USB 2.0 Connector (CN17)
Two USB 2.0 compliant connectors are available on connector CN17. Table 30 provides the pinout of the USB
connector.
Note For proper operation at USB 2.0 speeds, be sure to use a cable that is rated for USB 2.0, such as the
cable kit supplied by RTD.
Table 30 USB Connector (CN17)
Pin Signal Function In/Out
1 VCC1 Supply +5 V to USB1 out
2 VCC2 Supply +5 V to USB2 out
3 DATA1– Bidirectional data line for USB1 in/out
4 DATA2– Bidirectional data line for USB2 in/out
5 DATA1+ Bidirectional data line for USB1 in/out
6 DATA2+ Bidirectional data line for USB2 in/out
7 GND Ground out
8 GND Ground out
9 GND Ground out
10 GND Ground out
