102

CMX158886 cpuModule

BDM-610000049

Rev G

Table 72

USB — 9-Pin D Connector (male)

IDAN Pin #

Signal

Function

Mode

1

VCC1

+5 V to USB1

output

2

Data USB1–

USB1 Data–

input/output

3

Data USB1+

USB1 Data+

input/output

4

GND

Ground

—

5

GND

Ground

—

6

VCC2

+5 V to USB2

output

7

Data USB2–

USB2 Data–

input/output

8

Data USB2+

USB2 Data+

input/output

9

GND

Ground

—

Table 73

Ethernet — 9-Pin D Connector (female)

IDAN Pin #

10Base-T

Adapter Pin #

Signal

CPU Pin #

1

1

Receive +

1

2

2

Reserved

3

3

3

Transmit +

5

4

4

Reserved

7

5

5

Ground

9

6

6

Receive -

2

7

7

Reserved

4

8

8

Transmit -

6

9

—

Reserved

8
