BDM-610000049 Rev G Chapter 3: Connecting the cpuModule 23
Chapter 3 Connecting the cpuModule
This chapter provides information on all CMX158886 cpuModule connectors.
Proper Grounding Techniques —page 24
Connector Locations —page 24
Auxiliary Power (CN3)—page 26
Utility Port Connector (CN5)—page 28
SVGA Video Connector (CN18)—page 31
LVDS Flat Panel Video Connector (CN19)—page 33
EIDE Connector (CN10)—page 34
ATA/IDE Disk Chip Socket (U16)—page 35
Serial Port 1 (CN7) and Serial Port 2 (CN8)—page 37
multiPort™ (CN6)—page 42
USB 2.0 Connector (CN17)—page 45
Ethernet (10/100Base-T and -TX) Connector (CN20)—page 47
Audio (CN11)—page 48
PC/104-Plus PCI Bus (CN16)—page 49
Bridge Link (CN4)—page 52
External Power Management (CN12)—page 53
Optional RTC Battery Input (CN13)—page 53
Fan Power, +5 V (CN14)—page 53
Fan Power, Switched (CN15)—page 54
