BDM-610000049 Rev G Chapter 3: Connecting the cpuModule 31
SVGA Video Connector (CN18)
Table 11 provides the pinout of the video connector.
Facing the connector pins of the SVGA Video connector (CN18), the pinout is:
Table 11 SVGA Video Connector (CN18)
Pin Signal Function In/Out
1 VSYNC Vertical Sync out
2 HSYNC Horizontal Sync out
3 DDCSCL Monitor Communications Clock out
4 RED Red Analog Output out
5 DDCSDA Monitor Communications Data bidirectional
6 GREEN Green Analog Output out
7 PWR +5 V out
8 BLUE Blue Analog Output out
9 GND Ground out
10 GND Ground out
9 7 5 3 1
GND PWR DDCSDA DDCSCL VSYNC
GND BLUE GREEN RED HSYNC
10 8 6 4 2
