Appendix C: IDAN™ Dimensions and Pinout
105
External I/O Connections (BRG version only)
An additional connector is added to the IDAN PCI to ISA bridge configuration to allow additional digital I/O
signals to be accessible from outside the IDAN frame. The pinout for this connection is shown in the table below.
Table 75
aDIO — 37-Pin D Connector (female)
BRG Pin #
Function
IDAN Pin #
1
P1-0
1
2
GND
20
3
P1-1
2
4
GND
21
5
P1-2
3
6
GND
22
7
P1-3
4
8
GND
23
9
P1-4
5
10
GND
24
11
P1-5
6
12
GND
25
13
P1-6
7
14
GND
26
15
P1-7
8
16
GND
27
17
P1-Strobe
9
18
GND
28
19
P2-0
10
20
GND
29
21
P2-1
11
22
GND
30
23
P2-2
12
24
GND
31
25
P2-3
13
26
GND
32
27
P2-4
14
28
GND
33
29
P2-5
15
30
GND
34
31
P2-6
16
32
GND
35
33
P2-7
17
