Chapter 1 — Using the CN2G Handheld Computer
18
CN2G Handheld Computer User’s Manual
6
Remove the battery and set it aside.
7
Pull the tab attached to the SD card toward the bottom of the
CN2G.
rd
Tab
8
Remove the SD card from the CN2G.
To insert the SD card
1
Before inserting the SD card, you must attach one of the
pull-tabs that ships with the CN2G. An SD card without a
pull-tab can be very difficult to remove.
SD Card
Tab
2
Align the SD card as shown in the next illustration, and insert
the SD card into the slot.
SD card
Tab
3
Align the battery contacts as shown in the next illustration,
and insert the battery in the battery compartment. Press
down on the battery until it clicks into place.
